Samtec EHF Series Straight Surface PCB Header, 40 Contacts, 1.27 mm Pitch, 2 Row, Shrouded EHF-120-01-L-D-SM-P-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec EHF Series Straight Surface PCB Header, 40 Contacts, 1.27 mm Pitch, 2 Row, Shrouded EHF-120-01-L-D-SM-P-TR

Name: Samtec EHF Series Straight Surface PCB Header, 40 Contacts, 1.27 mm Pitch, 2 Row, Shrouded EHF-120-01-L-D-SM-P-TR
Brand: Samtec
SKU: 166461
Price: 10.08 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Brand	Samtec
Orientation	Straight
Model	EHF-120-01-L-D-SM-P-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	EHF
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold Flash
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Cable

Key Features

The header uses a robust liquid crystal polymer housing for durability.
Contacts are made of phosphor bronze with gold flash plating for excellent conductivity.
It provides a secure board-to-cable connection system with a male contact gender.
The product supports operating temperatures from -55°C up to 125°C.
Designed for solder termination with a polarizing notch and ejector latch for accurate mating.
Shrouded design protects contacts and ensures reliable cable lock capability.
Applicable in electronics manufacturing for PCB interconnections with high reliability.

Product Description

Samtec EHF-120-01-L-D-SM-P-TR is a high-quality PCB header from the EHF series providing a straight, surface mount, shrouded connector with 40 contacts and a pitch of 1.27 mm across 2 rows.

This header features a liquid crystal polymer housing known for high mechanical and thermal stability, ensuring long service life even under demanding conditions.

The contacts are phosphor bronze with a gold flash plating, providing excellent electrical conductivity and corrosion resistance. The male contact gender and board-to-cable connector system allow a secure and reliable mating interface.

The shrouded design protects contacts from damage and contamination, featuring a polarizing notch and an ejector latch mechanism for precise and safe mating and unmating operations.

Its solder termination type supports surface mount assembly processes, making it suitable for modern electronic device manufacturing. Operating temperature range from -55 °C to +125 °C allows usage in a broad spectrum of industrial, commercial, and electronic applications requiring durability and reliability.

The header uses a robust liquid crystal polymer housing for durability. Contacts are made of phosphor bronze with gold flash plating for excellent conductivity. It provides a secure board-to-cable connection system with a male contact gender.

The product supports operating temperatures from -55°C up to 125°C. Designed for solder termination with a polarizing notch and ejector latch for accurate mating. Shrouded design protects contacts and ensures reliable cable lock capability.

Applicable in electronics manufacturing for PCB interconnections with high reliability. This component is ideal for use in electronics and electrical manufacturing, such as PCB assembly lines, industrial controls, and communication equipment.

Browse more PCB Header connectors and related components at EnvMart for comprehensive electronic assembly solutions.
