Samtec EHF Series Straight Surface PCB Header 40 Contacts 1.27 mm Pitch 2 Row Shrouded EHF-120-01-L-D-SM-K-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec EHF Series Straight Surface PCB Header 40 Contacts 1.27 mm Pitch 2 Row Shrouded EHF-120-01-L-D-SM-K-TR

Name: Samtec EHF Series Straight Surface PCB Header 40 Contacts 1.27 mm Pitch 2 Row Shrouded EHF-120-01-L-D-SM-K-TR
Brand: Samtec
SKU: 166459
Price: 9.89 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Brand	Samtec
Orientation	Straight
Model	EHF-120-01-L-D-SM-K-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	EHF
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold Flash
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Cable

Key Features

The housing is made of durable Liquid Crystal Polymer.
Contacts are made from phosphor bronze with gold flash plating for reliable conductivity.
Designed for board-to-cable connectivity with a polarizing notch for accurate mating.
Termination type is solder, and connector gender is male.
Operating temperature range from -55°C to +125°C ensures reliability in harsh conditions.
The header includes an ejector latch and is suitable for surface mount applications.
No certifications or approvals are specified for this product.

Product Description

Samtec EHF-120-01-L-D-SM-K-TR is a high-performance straight surface mount PCB header designed for precise and reliable electronic assembly. It features 40 phosphor bronze contacts arranged in 2 rows with a 1.27 mm pitch. The housing material of Liquid Crystal Polymer ensures mechanical strength and stability under operating conditions. The shrouded design safeguards the contacts, promoting secure and accurate mating, aided by a polarizing notch and an ejector latch for ease of connection and disconnection.

This PCB header is intended for board-to-cable connector systems and terminated by soldering, with a male contact gender. Its operating temperature range spans from -55°C up to 125°C, suitable for demanding industrial, manufacturing, and electronic equipment environments where robust connectivity is essential. Gold flash plating on contacts ensures good electrical conductivity and resistance to corrosion.

The product is particularly suited for applications in electronics components manufacturing, electrical control systems, embedded devices, and precision instrumentation. Its surface mount capability enables compact assembly on printed circuit boards. Although no formal certifications are listed, it meets industry requirements for durable connection hardware.

The housing is Liquid Crystal Polymer providing strength and durability. Phosphor bronze contacts with gold flash plating enhance conductivity. Polarizing notch and ejector latch assist in reliable mating. Surface mount design for easy PCB integration.

Operating temperature range enables use in varied environmental conditions. Male contact gender with solder termination type. Designed for board-to-cable connector systems.

Samtec EHF Series PCB Headers are a trustworthy choice for precision electronic applications requiring 40-contact, 2-row connectors with 1.27 mm pitch and shrouded construction. Explore more products in our PCB Header category for suitable complementary components and connectors to complete your electronic design and manufacturing projects.
