Block PCB Transformer 6 V AC 2 Output Pin DIN EN 61558-2-6 IEC 61558-2-1 VDE 0570 Teil 2-6 FL 30/6

Block FL 30/6 PCB Transformer is a high-quality, dual secondary output transformer designed for PCB mounting with pin type mount. It provides a stable 6 V AC output from dual primary voltages of 115 V AC and 230 V AC, operating efficiently at 50 to 60 Hz frequency. The low-profile and compact design (68mm x 35.8mm x 57mm) makes it suitable for space-constrained electronic assemblies.

Manufactured in Germany, this transformer features vacuum epoxy resin moulding rated to UL94-V0, ensuring high safety standards and electrical insulation. The unit withstands a maximum operating temperature of 40°C and an isolation voltage rating of 5000 V, supporting robust and safe electrical performance.

Certified to comply with DIN EN 61558-2-6, IEC 61558-2-1, VDE 0570 Teil 2-6, IEC 61558-2-4, C-UL-US, and several other recognized industry standards, the FL 30/6 transformer is suited for a variety of industrial, electronic, and power supply applications. Its dual secondary output windings allow for flexible connection configurations in series or parallel.

The transformer is vacuum epoxy resin moulded, includes double section glass fibre reinforced polyamide bobbins, and has been 100% electrical and flash tested for quality assurance. This results in low inter-winding capacitance and minimal radiated noise, making it well suited even for sensitive electronics environments.

Ideal for use in industrial electronics, laboratory equipment, power supplies, and control devices, it offers reliable and efficient voltage transformation with guaranteed safety compliance.

Dual secondary output pins provide 6 V AC output voltage. Supports dual primary voltages of 115 V AC and 230 V AC at 50 to 60 Hz. Compact low profile design with dimensions 68mm length, 35.8mm width, and 57mm depth. Constructed with vacuum epoxy resin moulded to UL94-V0 rating for safety.

Meets multiple international safety standards including DIN EN 61558-2-6 and IEC approvals. Maximum operating temperature of 40°C ensures stable performance under normal industrial conditions. Isolation voltage rated at 5000 V for enhanced electrical safety.

Low inter-winding capacitance and low radiated noise for sensitive electronic applications. Ideal for industrial and electronic applications requiring reliable PCB transformers. Explore the extensive range of PCB Transformers and related electronics components at EnvMart for professional industrial, laboratory, and manufacturing solutions.
