Block PCB Transformer 24VA Dual Secondary Winding 15 V ac 2 Output Pin Mount FL 24/15

The Block FL 24/15 PCB Transformer is a high-quality power component designed for electronic assemblies needing 24VA rating with dual secondary AC outputs at 15 V. It accepts primary voltages of 115 V ac or 230 V ac with a frequency range of 50 to 60 Hz, ideal for worldwide applications.

This transformer is a pin mount type with a low profile and compact dimensions (68mm length, 31.4mm width, 57mm depth), making it appropriate for space-constrained printed circuit board designs. It weighs approximately 980 grams, balancing durability with manageable size.

Encased in vacuum epoxy resin molded to UL94-V0 standards, it offers flame retardancy and robust protection. The dual secondary winding allows series or parallel configurations for flexible voltage outputs. The insulation withstands up to 5000 V, ensuring safe and reliable electrical isolation suitable for sensitive electronics.

Standards compliance includes C-UL-US, IEC 61558-2-4, VDE 0570, DIN EN certifications, and UL 94 V-0 flame rating certifications. It is manufactured in Germany, reflecting stringent quality controls.

This transformer is highly suitable for industrial, laboratory, HVAC, manufacturing, and commercial power supply systems requiring efficient and safe PCB transformers. Its low inter-winding capacitance and low radiated noise help minimize electromagnetic interference, improving system reliability.

This transformer supports dual 115 V ac or 230 V ac primary voltage operation. It features pin mount type and a compact low profile design. Industry-approved standards include C-UL-US, IEC 61558 series, VDE 0570, and DIN EN certifications.

The device operates efficiently at 50 to 60 Hz frequency with a maximum temperature of 40°C. Constructed with vacuum epoxy resin moulding achieving UL94-V0 flame rating for safety. Its structure provides 5000 V isolation voltage ensuring excellent electrical insulation.

Extra fixing holes ensure secure board mounting in industrial electronics environments. Weight of 980 grams, and dimensions optimized for compact PCB integration. Suitable for industrial, laboratory, and power supply applications requiring reliable AC transformer solutions.
