Block 15 V ac 2 Output Pin PCB Transformer, Dual Secondary Winding, 42VA Power, Pin Mount FL 42/15

The Block FL 42/15 is a high-quality 15 V ac 2 Output Pin PCB Transformer with a power rating of 42VA, suitable for electronics and electrical power supply applications. It features dual secondary windings and is designed for pin mount installation on printed circuit boards, offering a compact form factor with dimensions of 83.5 mm length, 39 mm width, and 70 mm depth.

This transformer supports dual primary voltages at 115 V ac and 230 V ac, making it adaptable for different input power sources. Its robust construction includes vacuum epoxy resin moulding to UL94-V0 flame-retardant standard and double section glass fibre reinforced polyamide bobbins that ensure mechanical strength and electrical insulation.

The device has a maximum operating temperature of 40°C and provides an isolation voltage rating of 5000 V for safe electrical separation. It complies with DIN EN 61558-2-4, IEC 61558-2-4, DIN EN 61558-2-6, IEC 61558-2-6, and VDE 0570 standards, ensuring it meets stringent quality and safety requirements.

Additional features include low inter-winding capacitance and low radiated noise, providing enhanced suitability for sensitive electronic circuits. Extra fixing holes are provided for secure PCB mounting. The transformer operates efficiently within frequency ranges from 50 Hz up to a maximum of 60 Hz, covering most regional power frequency specifications.

This transformer supports primary voltages of 115 V ac and 230 V ac. Dual secondary windings provide 2 outputs for circuit applications. Compact dimensions suitable for PCB mounting: 83.5 x 39 x 70 mm. Constructed with vacuum epoxy resin moulding to UL94-V0 standard and reinforced bobbins.

Maximum operating temperature of 40°C and isolation voltage of 5000 V. Complies with multiple international standards and certifications for safety and quality. Low inter-winding capacitance and low noise for electrical performance.

Extra fixing holes provide secure mounting on PCB. Frequency range of 50 to 60 Hz for versatile power applications.

This Block PCB Transformer FL 42/15 is ideal for industrial, commercial electronics, laboratory equipment, HVAC controllers, and manufacturing machines that require reliable and certified power conversion solutions. It offers compact design combined with high safety and performance standards.
