Wurth Elektronik 5 V 1 Output Surface PCB Transformer RoHS IEC 61010 750316032

Name: Wurth Elektronik 5 V 1 Output Surface PCB Transformer RoHS IEC 61010 750316032
Brand: Wurth Elektronik
SKU: 100358
Price: 6.99 USD
Availability: InStock



Category PCB Transformer Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Length	10.41mm
Depth	12.32mm
Operating Temp	-40°C to 125°C
Width	11.89mm
Mount Type	Surface
Series	MID-PPTI
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Interfaces	LAN
Number of outputs	1
Winding Type	Dual Secondary, Dual Primary
Standards/Approvals	RoHS, IEC 61010
Number of Pins	6
Primary Voltage	3.3 V dc
Secondary Voltage	5 V
Maximum Operating Frequency	150kHz
PCB Transformer Current	1A

Key Features

Compact surface mount PCB transformer with low profile design.
Primary voltage is 3.3 V dc with a secondary voltage output of 5 V.
Single output with 1A current capacity suitable for interface power supplies.
Operating temperature from -40°C to 125°C ensures application in harsh environments.
Small dimensions of 10.41mm length, 11.89mm width, and 12.32mm depth for space-saving PCB layouts.
Dual primary and dual secondary winding for efficient push-pull transformer operation.
Maximum operating frequency is 150 kHz for high-speed applications.
Complies with RoHS and IEC 61010 standards for quality and safety.

Product Description

Wurth Elektronik 750316032 is a 5 V 1 output surface PCB transformer designed for isolated interface power supplies requiring RoHS compliance and IEC 61010 certification. The device operates at a primary voltage of 3.3 V dc and provides a single secondary output of 5 V with a current capacity of 1 A.

This transformer features a compact, low profile surface mount design with physical dimensions of 10.41 mm length, 11.89 mm width, and 12.32 mm depth, making it ideal for densely populated PCBs. It utilizes a push-pull MID-PPTI series configuration with dual primary and secondary windings to ensure efficient energy transfer at frequencies up to 150 kHz.

Engineered to operate within a broad temperature range from -40°C up to 125°C, it can reliably perform in challenging industrial and medical environments. Key applications include isolated interface power supply for communication protocols such as CAN, RS-485, RS-422, RS-232, SPI, and I2C, as well as use in PLC analog and digital I/O modules, AC motor drives, uninterruptible power supplies (UPS), solar inverters, protection relays, and polyphase energy meters.

The transformer is RoHS compliant and meets IEC 61010 safety standards, ensuring environmentally responsible and safe use in various sectors. Manufactured in China, the product follows international quality and production practices.

Compact surface mount design for dense PCB integration. Operating voltage: 3.3 V dc primary and 5 V secondary output. Current rating: 1 ampere suitable for low power isolated interfaces. Wide operating temperature range from -40°C to 125°C for reliability.

Dual primary and secondary winding topology enabling push-pull operation. High maximum operating frequency of 150 kHz for efficient power transfer. Compliant with RoHS and IEC 61010 standards for safety and environmental regulations.

Used in industrial automation, medical equipment, solar inverters, and energy meters. Origin: China ensuring adherence to international manufacturing standards. Explore more PCB Transformers and electronic components suitable for industrial and commercial applications at EnvMart.
