Samtec IPL1 Series Straight Surface PCB Header 24 Contacts 2.54 mm Pitch 2 Row Shrouded IPL1

Samtec IPL1 Series Straight Surface PCB Header IPL1 is a high-quality wire-to-board connector designed for electronic circuit applications requiring precision and reliability. The header has 24 male contacts arranged in a dual-row layout with a standard 2.54 mm pitch, optimized for dense PCB designs. Its housing is constructed from Liquid Crystal Polymer, providing excellent mechanical durability and thermal stability.

The contact pins are made of phosphor bronze, which ensures durable electrical conductivity and mechanical strength. These contacts are plated with gold to provide superior corrosion resistance, enhancing the longevity and performance of the connection in industrial and commercial settings.

This PCB header uses surface mount technology (SMT) for easy assembly and solder termination, supporting efficient manufacturing processes. The shrouded housing design provides polarized mating to prevent incorrect connections and shields the contacts against mechanical damage during handling and operation.

With an operating voltage rating of 675 V and a current rating of 3.8 A, this header is suitable for a wide range of electronics, including industrial control equipment, instrumentation, and communication devices. It is capable of withstanding temperatures from -55°C to +125°C, making it ideal for use in challenging environmental conditions.

The Samtec IPL1 series ensures reliable and robust electrical connections and is widely used across industrial plants, commercial electronics, telecommunications, and manufacturing environments requiring stable PCB interconnections.

The header features 24 male contacts arranged in 2 rows. Contacts have a 2.54 mm pitch for standard PCB mounting. Housing is made from durable Liquid Crystal Polymer material. Phosphor Bronze contact material provides excellent conductivity.

Gold plating on contacts ensures corrosion resistance and reliable signal integrity. Mount type is surface mount designed for PCB installation. Shrouded design offers polarization and protection for contacts. Operational voltage rating of 675 V and current rating of 3.8 A.

Temperature rating from -55°C to +125°C suitable for harsh environments. Termination type is solder ensuring secure electrical connections. Explore more PCB Headers from Samtec at EnvMart for your electronic component needs.
