APEM LED Indicator Green, Panel Mount, IP67, Lead Wire, 22.2 mm, 12 - 24V DC QH22L28GC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | APEM |
| Length | 5.5mm |
| Model | QH22L28GC |
| IP Rating | IP67 |
| Series | QH series |
| Number Of Leds | 1 |
| Maximum forward current | 20mA |
| Viewing angle | 30° - 100° |
| Sub Type | LED Indicator |
| Terminal type | Lead Wire |
| Supply Voltage | 12 to 24 V dc at 10 mA - 20 mA |
| Lens Colour | Green |
| Luminous Intensity | 350mcd |
| Standards/Approvals | RoHS |
| LED Colour | Green |
| Lens Finish | Diffused |
| Maximum Supply Voltage | 24V dc |
| Minimum Supply Voltage | 12V |
| Mount Hole Size | 22.2 mm |
| Multicolour/Single Colour | Single Colour |
| LED Orientation | Top |
| Manufacturing | Can be used with an emergency stop button. The halo ring could be on continuously for poorly lit areas, or illuminate when the E-Stop is activated |
Key Features
- Features a green LED indicator for clear visual signaling.
- Panel mount design with a 22.2 mm hole size provides secure installation.
- Sealed to IP67, offering outstanding environmental protection in demanding applications.
- Simple lead wire termination enables fast wiring and easy connection.
- Compatible with supply voltages of 12 to 24 V DC at 10 - 20 mA current.
- Utilizes one high-brightness LED for efficient illumination.
- Diffused lens finish ensures wide, uniform light output.
- Luminous intensity of 350 mcd with a viewing angle of 30° to 100°.
Product Description
APEM presents the QH22L28GC LED indicator, engineered for high-performance panel-mounted signaling in a wide range of industrial and commercial applications. This indicator features a single green LED, a 22.2 mm mount hole, and advanced sealing rated at IP67, making it suitable for both interior and rugged environmental conditions.
The QH series indicator is designed for zero-depth mounting behind a panel, held securely by the nut of the main switch and an adhesive gasket. The lead wire termination style allows for quick and simple installation, supporting flexible integration into control or display panels.
Features a distinguished green lens color with a diffused finish for uniform illumination. Operates at supply voltages from 12 to 24 V DC, consuming 10 - 20 mA, and delivers a bright visual alert at a luminous intensity of 350 mcd.
Wide viewing angle of 30° - 100°, easily visible from various positions. Robust, compact 5.5 mm lens length and IP67-rated ingress protection against water and dust. Ideal for control consoles, emergency stop indicators, transportation door indicators, access control status, and automated manufacturing panels.
Country of Origin: United Kingdom.
Suitable for industrial signaling, laboratory automation, vehicle dashboards, and public or commercial infrastructure installations. Supports safety and operational monitoring in demanding environments where reliable visual indication is critical.
Set your project apart with the style and utility of the APEM QH22L28GC - a proven solution in engineered LED indication. For more LED indicators and trusted APEM products, explore the full range of electronics and panel mount solutions on EnvMart.
Explore more products in our Panel Mount Indicator category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at supply voltages from 12 to 24 V DC, consuming between 10 mA and 20 mA of current.
This model has an IP67 rating, providing excellent protection against dust and water ingress.
The luminous intensity is 350 mcd, ensuring clear visibility in various lighting conditions.
It features a wide viewing angle of 30° to 100°, allowing for visibility from different positions.
The mounting hole size is 22.2 mm, designed for secure installation in panels.
It uses a lead wire termination style, which allows for quick and simple installation.
The lens color is green, designed to provide clear visual signaling.
It utilizes a single high-brightness LED for efficient illumination.
The lens length is 5.5 mm, contributing to its compact design.
Yes, it complies with RoHS standards, ensuring it meets environmental regulations.
The APEM QH22L28GC is manufactured in the United Kingdom.
It is suitable for industrial signaling, laboratory automation, vehicle dashboards, and public infrastructure installations.
