Schneider Electric Miniature Circuit Breaker, 2-Pole, 8A, Type D, 125 V DC, 20 kA Breaking Capacity Multi9
Specifications
| Country of Origin | France |
|---|---|
| Range | Multi 9 |
| Brand | Schneider Electric |
| Height | 103mm |
| Model | Multi9 |
| Depth | 72mm |
| IP Rating | IP40, IP20 |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 8A |
| Series | Multi9 |
| Terminal type | Tunnel |
| Breaking Capacity | 20kA |
| Number of Poles | 2 |
| Standards/Approvals | EN, GB, IEC, UL |
| Rated DC Voltage | 125V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Offers 20 kA breaking capacity for enhanced short circuit protection.
- Designed for DIN rail mounting with tunnel-type terminals for secure connections.
- IP40 and IP20 rated enclosure ensures protection against solid object ingress.
- Conforms to EN, GB, IEC, and UL standards for international reliability.
- Equipped with a toggle switch reset actuator for easy manual operation.
- Trip mechanism employs thermal magnetic technology for precise overload and short circuit protection.
- Manufactured in France, guaranteeing high quality and durability.
Product Description
Schneider Electric M9F43208 Multi9 miniature circuit breaker is engineered for comprehensive circuit protection in electrical installations. This 2-pole device is rated for 8 amperes current with Type D trip characteristics, suitable for protecting circuits with high inrush currents.
Rated for 125 V DC, it effectively interrupts faults with a breaking capacity of 20 kA ensuring safety and longevity of electrical systems. The thermal magnetic tripping mechanism offers combined protection against both overloads and short circuits.
Designed for easy DIN rail mounting, its compact dimensions of 103 mm height, 36 mm width, and 72 mm depth make it ideal for varied electrical panels. The tunnel terminal type secure wiring and provide reliability in connection.
The device meets IP40 and IP20 protection ratings, safeguarding internal components from dust and inadvertent contact. Meeting international standards including EN, GB, IEC, and UL, this MCB is suited for industrial, commercial, and residential electrical applications.
Operating via a toggle switch reset actuator, the circuit breaker simplifies manual reset after trips. Manufactured in France, the build quality assures durability and compliance with stringent performance criteria.
Offers 20 kA breaking capacity for enhanced short circuit protection. Designed for DIN rail mounting with tunnel-type terminals for secure connections. IP40 and IP20 rated enclosure ensures protection against solid object ingress.
Dimensions: 103mm height, 36mm width, 72mm depth for compact installation. Conforms to EN, GB, IEC, and UL standards for international reliability. Equipped with a toggle switch reset actuator for easy manual operation. Trip mechanism employs thermal magnetic technology for precise overload and short circuit protection.
Manufactured in France, guaranteeing high quality and durability.
This miniature circuit breaker is ideal for use in industrial automation, electrical distribution, control panels, and other environments requiring high reliability and safety. Explore more products like this in the Miniature Circuit Breaker category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a breaking capacity of 20 kA, providing enhanced short circuit protection.
It is rated for 8 amperes current, suitable for circuits with high inrush currents.
This circuit breaker is designed for DIN rail mounting, making it easy to install in electrical panels.
The dimensions are 103 mm in height, 36 mm in width, and 72 mm in depth.
It is rated for 125 V DC, allowing it to effectively interrupt faults in DC circuits.
It features tunnel-type terminals for secure and reliable wiring connections.
This unit has IP40 and IP20 ratings, which protect against solid object ingress and inadvertent contact.
It uses a thermal magnetic tripping mechanism for precise overload and short circuit protection.
It conforms to EN, GB, IEC, and UL standards, ensuring international reliability.
It is equipped with a toggle switch reset actuator for easy manual operation after a trip.
This model is suitable for industrial automation, electrical distribution, and control panels, among other environments requiring high reliability.
It is manufactured in France, ensuring compliance with high quality and durability standards.
