Nexperia 30 V 1 A Surface Mount Schottky Diode 2-Pin SOD-323 PMEG3010BEA,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 30 V 1 A Surface Mount Schottky Diode 2-Pin SOD-323 PMEG3010BEA,115

Name: Nexperia 30 V 1 A Surface Mount Schottky Diode 2-Pin SOD-323 PMEG3010BEA,115
Brand: Nexperia
SKU: 162569
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.05mm
Length	1.8mm
Model	PMEG3010BEA,115
Width	1.35mm
Mount Type	Surface
Series	PMEG3010BEA
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	30V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	150μA
Peak Non-Repetitive Forward Surge Current Ifsm	10A
Maximum Forward Voltage Vf	560mV

Key Features

The diode features a maximum continuous forward current of 1 ampere.
It offers a peak reverse repetitive voltage rating of 30 volts.
The maximum forward voltage drop is 560 millivolts for improved efficiency.
Supports peak non-repetitive forward surge current up to 10 amperes.
Operates over a wide temperature range from -65°C to 150°C.
Surface mount package type SOD-323 allows compact PCB design.
Compliance with automotive standard AEC-Q101 ensures reliability.
Designed with low leakage current and low capacitance to minimize power losses.

Product Description

Nexperia PMEG3010BEA,115 is a high-efficiency 30 volt, 1 ampere Schottky barrier diode housed in an ultra-small, low-profile 2-pin SOD-323 surface mount package. This diode is engineered to provide low forward voltage drop, low leakage current, and high junction temperature capabilities, enhancing overall power efficiency and reliability in electronic circuits.

Its maximum continuous forward current rating of 1 A and a peak non-repetitive forward surge current of 10 A make it suitable for transient handling in power rectification applications. The diode features a peak reverse repetitive voltage of 30 V and low maximum forward voltage of 560 mV, which reduces energy dissipation and thermal stress during operation.

The operating temperature range from -65°C to 150°C and the compliance with the automotive AEC-Q101 standard ensure this diode's suitability for challenging industrial and automotive environments. Its compact SOD-323 package enables space-saving layouts on printed circuit boards, ideal for densely packed electronics.

Key attributes include a single diode configuration with 2 pins, optimized for low capacitance and negligible switching losses, which are critical for high-frequency power and signal applications.

The diode effectively reduces reverse leakage current for robust performance. Its low-profile surface mount design supports automated manufacturing processes. Applications extend to industrial power supplies, automotive systems, telecommunications, and consumer electronics.

China is the country of origin for this semiconductor device.

Choose Nexperia PMEG3010BEA,115 Schottky diodes for reliable and efficient power management in demanding engineering and manufacturing sectors. Explore more electronic components and semiconductor solutions in the Schottky Diodes & Rectifiers category at EnvMart for your professional needs.

Explore more products in our Schottky Diodes & Rectifiers category.
