Molex Pico-Clasp Series Right Angle Surface PCB Header 5 Contact, 1 mm Pitch, 1 Row, Shrouded 501568-0507
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Pico-Clasp |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin |
| Number of Contacts | 5 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 1mm |
Key Features
- Wire-to-board connector system designed for high density interconnection.
- Nylon housing material providing insulation and durability.
- Male brass contacts with tin plating for corrosion resistance.
- Right angle orientation suitable for surface mount applications.
- Operates reliably between -40°C and 105°C.
- Positive locking mechanism ensures secure mating.
- Compact 1.00 mm pitch allows use in small form factor PCBs.
- Termination type is solder for ease of assembly.
Product Description
The Molex 501568-0507 Pico-Clasp Series Right Angle Surface PCB Header is a compact, high-density wire-to-board connector system designed for electronic applications requiring a reliable connection in limited spaces. Featuring a 1 mm pitch and 5 contacts arranged in a single shrouded row, this connector facilitates secure mating with a positive lock mechanism integrated inside the header.
Constructed with a durable nylon housing, the connector provides excellent insulation and mechanical stability. The male contacts are made of brass with tin plating, promoting corrosion resistance and optimal electrical conductivity. This connector mounts via surface solder termination, ensuring a secure attachment to printed circuit boards.
Engineered for demanding environments, the Pico-Clasp header supports operating temperatures from -40°C up to 105°C with a current rating of 1 A and a voltage rating of 50 V. Its right angle orientation allows efficient use of PCB space and routing flexibility in device assembly.
This product is manufactured in Japan under stringent quality controls, making it suitable for industrial, commercial, and consumer electronic manufacturing applications. Wire-to-board connector system designed for high density interconnection.
Nylon housing material providing insulation and durability. Male brass contacts with tin plating for corrosion resistance. Right angle orientation suitable for surface mount applications. Operates reliably between -40°C and 105°C.
Rated voltage of 50 V and current of 1 A. Positive locking mechanism ensures secure mating. Compact 1.00 mm pitch allows use in small form factor PCBs. Termination type is solder for ease of assembly. Manufactured in Japan with high quality standards.
This Molex Pico-Clasp Series PCB Header caters to electronic manufacturing in sectors such as industrial automation, telecommunications, consumer electronics, and instrumentation. The small pitch and reliable locking system make it ideal for compact, high-performance assemblies.
Explore the Electronics Components and PCB Headers categories on EnvMart to discover comprehensive connector solutions and other electronic parts by Molex and other leading brands.
