Wurth Elektronik 2447 Series PCB Terminal Block, 8-Contact, 5 mm Pitch, Through Hole, 1 Row 691244700008

Name: Wurth Elektronik 2447 Series PCB Terminal Block, 8-Contact, 5 mm Pitch, Through Hole, 1 Row 691244700008
Brand: Wurth Elektronik
SKU: 159241
Price: 6.56 USD
Availability: InStock



Category PCB Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Italy
Voltage	450V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Vertical
Current	24A
Length	40mm
Depth	18mm
Width	11.2mm
Mount Type	Through Hole
Series	2447
Number of Rows	1
Pitch	5mm
Standards/Approvals	cULus, RoHS, VDE
Number of Contacts	8
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	30AWG
Maximum Wire Size AWG	12AWG

Key Features

Features 8 contact points for secure connectivity.
Has a 5 mm pitch spacing to fit standard PCB layouts.
Through hole mounting offers mechanical stability.
Supports current up to 24A and voltage rating of 450 V AC.
Compatible with wire sizes from 0.05 mm² to 3.31 mm².
Constructed in a vertical orientation with green color coding.
Meets industry standards including cULus, RoHS, and VDE.

Product Description

Wurth Elektronik 691244700008 PCB Terminal Block is a robust component designed for electrical circuit board applications. This terminal block features 8 contact points arranged in a single row with a 5 mm pitch, facilitating precise and reliable connections on printed circuit boards. Its through hole mount style ensures excellent mechanical stability when soldered onto PCBs.

With a current rating of up to 24 amperes and voltage capacity of 450 volts AC, this terminal block supports a wide range of industrial and commercial applications, including power distribution and signal transmission in electronic devices. Suitable for wire sizes between 0.05 mm² and 3.31 mm² (30 to 12 AWG), it accommodates various wiring standards.

The vertical orientation and green color allow for easy identification and integration in existing layouts. Its compact size, measuring 40 mm in length, 18 mm in depth, and 11.2 mm in width, helps maintain efficient use of PCB space. Additionally, the product complies with important safety and environmental standards such as cULus, RoHS, and VDE, ensuring reliability and regulatory compliance.

Features 8 contact points for secure connectivity. Has a 5 mm pitch spacing to fit standard PCB layouts. Through hole mounting offers mechanical stability. Supports current up to 24A and voltage rating of 450 V AC. Compatible with wire sizes from 0.05 mm² to 3.31 mm².

Constructed in a vertical orientation with green color coding. Compact dimensions: 40 mm length, 18 mm depth, and 11.2 mm width. Meets industry standards including cULus, RoHS, and VDE.

This terminal block is ideal for applications in electronics manufacturing, control panels, industrial automation, instrumentation, and power supply assemblies. It provides dependable and efficient electrical connections essential for high-performance electronic circuits.
