onsemi MOSFET Gate Driver, High Current Output 7.8 A, 16-Pin SOIC, 5-5.5 V, AEC-Q100 NCD57001DWR2G

onsemi NCD57001DWR2G MOSFET Gate Driver provides a high current output of 7.8 A, housed in a 16-pin SOIC package with operation supply voltage from 5 V to 5.5 V, making it ideal for power management IC applications. This device is designed to enhance system efficiency and improve pulse-width modulation signal integrity, supporting robust and safe switching in demanding industrial environments.

The driver offers high transient and electromagnetic immunity, active Miller clamp, and negative gate voltage features. It provides protection against overload and short circuits, preventing spurious gate turn-on and ensuring ruggedness in high voltage, high current switching scenarios.

The device operates reliably over a wide temperature range from -40°C to 125°C, meeting the automotive standard AEC-Q100, thereby supporting use in automotive and industrial power applications.

Galvanic isolation up to 5 kV separates the high voltage and low voltage sides, enhancing safety and protection in system designs.

This MOSFET gate driver is widely applicable in solar inverter technology, motor control processes, UPS systems, industrial power supplies, and welding machines, delivering precise and reliable gate drive control.

High current output of +4/-6 A at IGBT Miller plateau voltages. Short propagation delays with accurate timing matching. DESAT with soft turn-off functionality for enhanced protection. Active Miller clamp and negative gate voltage to prevent false triggering.

5 kV galvanic isolation for safety between high and low voltage circuits. Rugged design for fast slew rate, high voltage, and high current switching applications. Explore more in MOSFET Gate Drivers on EnvMart for advanced power management solutions.
