Finder Power Relay 48V AC Coil 10A Switching Current 3PDT PCB Pin Terminals 60.13.8.048.0040

Finder 60.13.8.048.0040 Power Relay offers reliable switching with a 48V AC coil voltage and 10A switching current capacity in a 3PDT contact configuration. This power relay is engineered for industrial, electrical, and automation applications requiring compact and efficient components.

Measuring 32.5mm in length, 36.4mm in width, and 54.2mm in height, with PCB pin terminals, it enables streamlined circuit integration and plug-in mounting for flexibility and quick installation. The coil resistance is 290 ohms and coil power consumption is 1.3W, making it energy efficient.

Its operational temperature range of -40°C to +70°C allows use in a wide variety of environments, from harsh outdoor conditions to controlled indoor setups. Silver Alloy contact material delivers excellent conductivity and durability, and the relay’s 3PDT configuration supports controlling three circuits simultaneously, simplifying complex control needs.

With a high switching AC voltage rating of 400V AC and a long functional life of up to 200,000 cycles, this relay ensures dependable operation in demanding situations. It conforms to RoHS environmental standards and is manufactured in Italy, assuring quality and regulatory compliance.

This device is ideal for industrial control panels, shipyards, hoists, cranes, wood-processing machinery, burners, boilers, furnaces, road and tunnel lighting, and electrical distribution and control systems. The robust isolation rating of 3.6kV between coil and contacts enhances electrical safety.

This power relay supports 3PDT contact configuration enabling control of three separate circuits simultaneously. The coil voltage is rated at 48V AC with a coil resistance of 290 ohms. High switching current capacity of 10A and switching AC voltage up to 400V AC for robust electrical performance.

Compact dimensions of 32.5mm length, 36.4mm width, and 54.2mm height facilitate mounting in space-constrained environments. PCB pin type terminals provide easy integration into circuit boards. Operating temperature range from -40°C to +70°C enables use in harsh and controlled environments.

Contact material is Silver Alloy ensuring excellent conductivity and durability. Designed for plug-in mounting with a long operational life of approximately 200,000 cycles. Complies with RoHS standards and is manufactured in Italy, guaranteeing quality and environmental compliance.

Suitable for industrial use including shipyards, control panels, hoists, cranes, wood-processing machinery, burners, boilers, furnaces, road and tunnel lighting, and electrical distribution systems.
