Schneider Electric Contactor, 110V AC Coil, 3-Pole, 40 A, 18.5 kW, Motor Control, DIN Rail Mount LC1D
Specifications
| Country of Origin | Indonesia |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 122mm |
| Model | LC1D |
| Depth | 120mm |
| Width | 55mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Power Rating | 18.5kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw Clamp |
| Number of Poles | 3 |
| Standards/Approvals | EAC, CCC, CSA, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 110V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 40A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 40A |
| Control Circuit Voltage Uc | 110V ac |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Operates at coil voltage of 110V AC with control circuit voltage matching.
- Supports 3 poles and has a contact current rating of 40 A with 690V AC contact voltage.
- Features 3 NO normal state contacts with 2 auxiliary contacts configured as 1 NO and 1 NC.
- Designed for DIN rail mounting with compact body dimensions of 122 mm length, 55 mm width, and 120 mm depth.
- Rated power of 18.5 kW suitable for various industrial motor control applications.
- Operates reliably within a temperature range of -5°C to 60°C.
- Includes screw clamp terminal type and IP20 finger-safe terminals with dual international markings.
- Built to last approximately six million mechanical cycles, ensuring long operational life.
Product Description
Schneider Electric LC1D40AF7 contactor is a robust, DIN rail mountable device designed for industrial motor control and resistive load applications with a coil voltage of 110V AC and a 3-pole configuration.
This contactor handles a contact current of 40 A and contact voltage of 690V AC, capable of controlling equipment up to 18.5 kW power rating. It features rapid response switching times between 4 to 26 milliseconds and includes built-in auxiliary contacts (1 NO and 1 NC) to remotely signal switching status to control systems.
The compact dimensions of 122 mm length, 55 mm width, and 120 mm depth make it suitable for tight control panel spaces, while screw clamp terminals with IP20 protection ensure safe and reliable connections. The device is designed for harsh environments, operating efficiently between -5°C and 60°C, ensuring high durability with an expected lifetime of around six million mechanical cycles.
Widely used across automotive industries, packing plants, chemical processing, and industrial manufacturing, this contactor supports a broad range of motor control and resistive load applications. Compliant with international standards such as EAC, CCC, CSA, IEC, RoHS, and UL, it represents a reliable choice for industrial automation systems requiring performance, safety, and ease of installation.
Operates reliably in demanding industrial environments. Compact DIN rail mounting design enables fast installation without special tools. Built-in auxiliary contacts support advanced control and monitoring. Robust construction and compliance with multiple safety standards.
Designed to reduce downtime with extended mechanical lifecycle.
This Schneider Electric LC1D40AF7 contactor is part of the TeSys D series, optimized for quick setup and integration in commercial and industrial motor control applications. Explore more Schneider Electric products and related Contactors in the Electronics & Electricals category at EnvMart for comprehensive industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a contact current rating of 40 A, allowing it to handle significant electrical loads in motor control applications.
The coil voltage for this contactor is 110V AC, which matches the control circuit voltage requirements.
It is rated for a power output of 18.5 kW, suitable for various industrial motor control applications.
The contactor has compact dimensions of 122 mm in length, 55 mm in width, and 120 mm in depth, making it suitable for tight spaces.
This model features a 3-pole configuration, allowing for effective control of three-phase motors.
It includes screw clamp terminals with IP20 protection, ensuring safe and reliable connections.
It operates reliably within a temperature range of -5°C to 60°C, suitable for various industrial environments.
The contactor includes two auxiliary contacts configured as 1 NO (Normally Open) and 1 NC (Normally Closed), which can be used for signaling purposes.
It complies with multiple international standards, including EAC, CCC, CSA, IEC, RoHS, and UL, ensuring safety and reliability in industrial applications.
This model is designed for motor control and resistive load applications, making it suitable for various industrial uses such as automotive and manufacturing.
It is designed for DIN rail mounting, allowing for quick and easy installation without the need for special tools.
This contactor is built to last approximately six million mechanical cycles, ensuring a long operational life in demanding applications.
