TDK Wirewound Surface Mount Inductor with Ferrite Core 68 μH ±20% 1.1 A Idc 6045 Package CLF6045NI-D
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 6mm |
| Brand | TDK |
| Height | 4.5mm |
| Length | 6.3mm |
| Model | CLF6045NI-D |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | CLF6045NI-D |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 1.1A |
| Maximum DC Resistance | 200mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- This inductor features a shielded wirewound construction for electromagnetic interference reduction.
- It has a compact 6045 package size with dimensions 6.3 mm length, 6 mm diameter, 4.5 mm height, and 6 mm depth.
- The ferrite core material provides high mechanical robustness and stable performance over temperature.
- Operates reliably between -55°C to 150°C, suitable for automotive applications with AEC-Q200 certification.
- The product is RoHS compliant and designed for surface mount PCB soldering with tape & reel packaging.
- It offers a low maximum DC resistance of 200 mΩ for efficient current flow.
- The maximum self-resonant frequency is 100 kHz, fitting for filtering and decoupling duties.
Product Description
TDK CLF6045NI-D Wirewound Surface Mount Inductor with Ferrite Core is a high-performance passive electronic component designed for use in DC/DC converters, automotive electronics, and filtering of supply voltages. This shielded inductor features a 68 μH inductance with ±20% tolerance and can handle a maximum DC current of 1.1 A, ensuring robust current handling capability in demanding circuits.
The inductor is built with a ferrite core and shielded construction, delivering high mechanical strength and effective electromagnetic shielding to reduce interference. Its dimensions include a package size of 6045 with physical measurements of 6.3 mm length, 6 mm diameter, 4.5 mm height, and 6 mm depth, making it suitable for compact PCB layouts and automated surface mount assembly.
Rated for operation between -55°C and 150°C, this component complies with the automotive AEC-Q200 standard, guaranteeing superior reliability for automotive and industrial electronics. The maximum DC resistance is low at 200 mΩ, which helps minimize power losses and improve efficiency. It is suitable for lead-free reflow soldering processes and comes in tape and reel packaging for efficient manufacturing integration.
This inductor is perfect for power supply filtering, coupling, and decoupling applications. Its shielding protects sensitive circuits from electromagnetic interference. The ferrite core supports stable inductance across temperature variations.
Compliance with RoHS ensures environmental safety standards. Packaging on tape and reel facilitates automated surface mount device assembly.
Common industrial applications include automotive electronics, DC/DC conversion circuits, filtering supply voltages, and electronics requiring high current handling with low power loss. This inductor provides a balance of performance, durability, and integration ease for professional electronics manufacturing.
Explore more Surface Mount Inductors and related electronic passive components in the Electronics & Electricals category on EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 68 μH with a tolerance of ±20%.
It can handle a maximum DC current of 1.1 A, ensuring robust performance in demanding applications.
The dimensions of this inductor are 6.3 mm in length, 6 mm in diameter, and 4.5 mm in height.
The maximum self-resonant frequency is 100 kHz, making it suitable for filtering and decoupling applications.
It operates reliably within a temperature range of -55°C to 150°C.
It is packaged in tape and reel format, facilitating automated surface mount assembly.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
The maximum DC resistance is 200 mΩ, which helps minimize power losses.
This model complies with the AEC-Q200 automotive standard, ensuring reliability for automotive applications.
It is constructed with a ferrite core, which provides high mechanical strength and stable performance.
It is suitable for DC/DC converters, automotive electronics, and filtering of supply voltages.
The termination style is surface mount, designed for PCB soldering.
