Samtec ASP Series Straight Surface PCB Socket 160-Contact 2 Row 0.5 mm Pitch Solder ASP-122952-01

Name: Samtec ASP Series Straight Surface PCB Socket 160-Contact 2 Row 0.5 mm Pitch Solder ASP-122952-01
Brand: Samtec
SKU: 154766
Price: 20.26 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	Costa Rica
Voltage	339V
Brand	Samtec
Orientation	Straight
Current	2.7A
Model	ASP-122952-01
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Series	ASP
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Terminal Assembly
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.5mm
Standards/Approvals	RoHS
Contact Plating	Gold over Nickel
Number of Contacts	160
Contact Gender	Male
Connector System	Board-to-Board
Stacking Height	10mm
Row Pitch	6.18mm

Key Features

The socket supports a current rating of 2.7 amperes.
Constructed with a Liquid Crystal Polymer housing for durability.
Offers a stacking height of 10 mm with a straight orientation.
Features gold over nickel plating on bronze contacts for enhanced conductivity and corrosion resistance.
Designed for board-to-board connector systems with a row pitch of 6.18 mm.
Operates within a temperature range of -55°C to 125°C.
Meets RoHS compliance standards for environmental safety.
Manufactured in Costa Rica ensuring quality production standards.

Product Description

Samtec ASP-122952-01 is a high-performance straight surface PCB socket specifically engineered for board-to-board applications, incorporating 160 contacts arranged in 2 rows with a 0.5 mm pitch for precision connection. This device is surface mount compatible and designed to handle a current of 2.7 amperes and a voltage of 339 volts, supporting varied industrial and electronic applications.

Its housing is made from liquid crystal polymer, providing robust mechanical and thermal stability, suitable for demanding environments spanning from -55°C up to 125°C. The bronze contacts plated with gold over nickel ensure reliable electrical connections while resisting corrosion, enhancing the socket's lifespan and performance.

The ASP series socket features a stacking height of 10 mm, facilitating compact and efficient PCB designs, while its straight orientation and 6.18 mm row pitch optimize connector alignment. This product complies with RoHS standards, emphasizing environmental compliance.

Commonly used in electronics manufacturing, telecommunications, and industrial control systems, this PCB socket provides a standardized and dependable interface for mezzanine cards and host boards.

The socket supports a current rating of 2.7 amperes. Constructed with a Liquid Crystal Polymer housing for durability. Offers a stacking height of 10 mm with a straight orientation. Features gold over nickel plating on bronze contacts for enhanced conductivity and corrosion resistance.

Designed for board-to-board connector systems with a row pitch of 6.18 mm. Operates within a temperature range of -55°C to 125°C. Meets RoHS compliance standards for environmental safety. Manufactured in Costa Rica ensuring quality production standards.
