Samtec CLP Series Right Angle Surface PCB Socket 10-Contact 2 Row 1.27 mm Pitch Solder CLP-105-02-F-D-BE

Samtec CLP-105-02-F-D-BE Right Angle Surface PCB Socket is a high-quality board-to-board PCB connector designed to provide secure and reliable electronic connections. This 10-contact 2-row socket features a 1.27 mm pitch and is engineered for surface mount solder termination to facilitate efficient automated assembly processes.

The housing is made from Liquid Crystal Polymer, offering excellent mechanical stability and heat resistance. Bronze contacts plated with gold ensure optimal conductivity and corrosion resistance, supporting current up to 3.4A and voltage up to 395V. Operating reliably in temperatures ranging from -55°C to 125°C, this connector is suitable for demanding industrial, electronic, and manufacturing environments.

Its right angle orientation and dual-row configuration make it ideal for compact board-to-board interconnections, commonly found in communication equipment, industrial control systems, and consumer electronics. The CLP series incorporates extended life product (E.L.P.™) technology and the innovative low-profile dual wipe Tiger Claw™ contacts to enhance durability and performance.

This surface mount device supports both top and bottom entry styles, increasing versatility in PCB layout design. The connector is manufactured in the United States, ensuring adherence to industry quality standards despite the absence of specific certifications.

Key applications include use in industrial automation, telecommunications, consumer electronics, and other electronic assemblies requiring dependable PCB Sockets. Constructed with liquid crystal polymer housing ensuring durability.

Features bronze contacts with gold plating for reliable conductivity. Rated for 3.4A current and 395V voltage, suitable for robust electronic connections. Operates reliably between -55°C and 125°C temperature range. Right angle orientation supports board-to-board configurations with a compact dual-row design.

Part of the CLP Series, suitable for industrial and electronic equipment applications. Surface mount technology compatible for automated PCB assembly. Manufactured in the United States adhering to quality standards. Offers low profile dual wipe Tiger Claw™ contact technology for long service life.

Compatible with top or bottom entry styles for versatile use. Explore more PCB socket solutions and electronic components at EnvMart to find the perfect fit for your industrial and electronic projects.
