Molex Mega-Fit Series Right Angle Through Hole PCB Header 2 Contact 5.7 mm Pitch 2 Row Shrouded 76825-0002
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 23A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Mega-Fit |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 5.7mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Operating voltage rating of 600V suitable for various electrical applications.
- Supports a continuous current of 23A ensuring efficient power transmission.
- Constructed with thermoplastic housing for durability and thermal resistance.
- Features a male contact gender with copper alloy contact material plated in tin for reliable conductivity.
- Designed for through hole mount type providing robust mechanical and electrical connection to PCBs.
- Shrouded design offers protection and proper alignment ensuring secure mating.
- Operates reliably between -40°C to 105°C accommodating diverse environmental conditions.
- Row pitch of 5.7 mm with 2 rows supporting compact board layouts.
Product Description
Molex 76825-0002 is a Mega-Fit Series right angle through hole PCB Header featuring 2 male contacts with a precise 5.7 mm pitch arranged in 2 rows. This connector is designed for wire-to-board applications where reliable electrical and mechanical connection is essential.
The housing is made from durable thermoplastic, ensuring performance stability in demanding industrial and commercial environments. The copper alloy contacts are plated with tin to provide excellent conductivity and corrosion resistance. Intended for through hole solder termination, this header supports a maximum continuous current of 23 amperes and a voltage of up to 600 volts, suitable for power delivery circuits and electronic assemblies.
Its shrouded construction helps prevent misalignment and accidental contact, enhancing safety and connection integrity during installation and operation. Operating over a temperature range from -40°C to 105°C, this product is reliable across various temperature conditions encountered in industrial, laboratory, and manufacturing applications.
Key uses include PCB assembly in electronic components, power supply systems, industrial machinery controls, and automotive electronics. The compact design allows effective space-saving on PCBs while maintaining robust connection standards.
Operating voltage rating of 600V suitable for various electrical applications. Supports a continuous current of 23A ensuring efficient power transmission. Constructed with thermoplastic housing for durability and thermal resistance.
Features a male contact gender with copper alloy material plated in tin for reliable conductivity. Designed for through hole mount type providing robust mechanical and electrical connection to PCBs. Shrouded design offers protection and proper alignment ensuring secure mating.
Operates reliably between -40°C to 105°C accommodating diverse environmental conditions. Row pitch of 5.7 mm with 2 rows supporting compact board layouts. Choose Molex Mega-Fit Series PCB Headers for dependable electrical connections in precision electronics manufacturing and assembly workflows.
Explore the full range of PCB Headers and related components in the Electronics & Electricals category on EnvMart for comprehensive industrial sourcing.
