Molex Right Angle Surface Mount Female USB Type B Connector USB 2.0 1 Port 30V 1.8A 105164-0001
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 30V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1.8A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | 1051 |
| Number Of Ports | 1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| USB Type | USB Type B |
| Connector Gender | Female |
| USB Specification | USB 2.0 |
Key Features
- Features one-port USB Type B female connector with right angle orientation for convenient surface mounting.
- Rated for a maximum current of 1.8A and voltage of 30V, ensuring reliable power delivery.
- Contacts made from copper alloy providing good conductivity and durability.
- Operates within temperature range from -30°C to 85°C, suitable for varied industrial environments.
- Termination type is solder, providing secure and efficient PCB mounting.
- Complies with series 1051 and meets strict quality standards without hazardous area certification.
- Manufactured in China, ensuring consistent production quality.
Product Description
Molex 105164-0001 is a high-quality USB Type B connector designed for surface mount applications in industrial and electronic components. This right angle, female connector is optimized for USB 2.0 compliance providing effective data transfer and power capabilities at 30 volts and 1.8 amps current rating.
The connector features a solder termination type which allows secure attachment to circuit boards. The copper alloy contact material ensures robust connectivity with excellent electrical conduction and corrosion resistance. It operates reliably within a temperature range of -30°C to 85°C, making it suitable for diverse operating conditions in manufacturing, electronics, and embedded systems.
This single-port USB Type B connector is part of the 1051 series and is designed for surface mounting, enabling streamlined board layouts.
Molex’s product ensures high performance and durability, ideal for industrial, electronic, and power connector applications requiring USB 2.0 standard compliance for data and power transmission.
One port USB Type B female connector with right angle orientation. Surface mount design with solder termination for PCB integration. Copper alloy contacts provide electrical reliability and longevity. Operates from -30°C to 85°C temperature range.
Rated for 30V voltage and 1.8A current specifications. Part of the Molex 1051 series connectors. Manufactured in China to exacting standards.
This component is well suited for electronics manufacturing, PCB assembly, industrial automation, and electronic repair markets. Browse EnvMart for quality USB Connectors and related electronic components to ensure system efficiency and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this USB Type B connector is 1.8A.
This connector operates at a maximum voltage of 30V.
It operates reliably within a temperature range of -30°C to 85°C.
The termination type for this connector is solder, allowing secure attachment to circuit boards.
The contacts are made from copper alloy, providing good conductivity and durability.
This USB connector features one port.
This connector has a right angle orientation for convenient surface mounting.
Yes, it is optimized for USB 2.0 compliance, ensuring effective data transfer and power capabilities.
This model is part of the Molex 1051 series connectors.
This connector is manufactured in China.
It is suitable for electronics manufacturing, PCB assembly, industrial automation, and electronic repair markets.
This connector supports surface mounting, enabling streamlined board layouts.
