Molex Right Angle Surface Mount Female 1 Port USB Type B Connector USB 2.0 30V 1.8A 47346-1001
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 30V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1.8A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | 4734 |
| Number Of Ports | 1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| USB Type | USB Type B |
| Connector Gender | Female |
| USB Specification | USB 2.0 |
Key Features
- Right angle orientation ensures efficient PCB space utilization.
- Surface mount design for easy soldering on PCB board.
- Supports USB Type B connectors compliant with USB 2.0 standard.
- Operates safely up to 30 volts and current of 1.8 amperes.
- Constructed with copper alloy contacts for reliable conductivity.
- Rated for operating temperatures between -30°C to 85°C.
- Solder termination type facilitates secure and durable connections.
- Compact one port design suitable for single USB connectivity needs.
Product Description
Molex 47346-1001 is a high-quality USB Type B connector designed for industrial and commercial electronic applications requiring a right angle surface mount female connector. This USB 2.0 compliant connector supports a current load of 1.8 amperes and is rated for operation at voltages up to 30 volts.
The connector features a compact single port design ideal for motherboard or device PCB assembly where space is critical. Its surface mount solder termination allows for reliable, secure PCB mounting improving production efficiency and board durability.
Constructed with copper alloy contact materials, this connector assures excellent electrical conductivity and robustness for long-term performance even in demanding temperature conditions ranging from -30°C to +85°C.
This model belongs to the 4734 series offering compatibility and interchangeability across Molex's USB Connector range. It supports a bottom mount micro-USB B receptacle without flange, suitable for numerous electronics and power connector assemblies.
Applications include computer peripherals, embedded systems, industrial control units, and other equipment requiring durable, standard USB 2.0 interface connectors. Right angle orientation optimizes PCB layout and connectivity.
Surface mount type facilitates automatic soldering processes. Compliance with USB 2.0 ensures broad compatibility and high-speed data transfer. Copper alloy contacts offer excellent electrical performance. Stable operation over wide temperature range -30°C to 85°C.
Supports a 1.8A current capacity suitable for various device power demands. Lead-free construction meeting environmental compliance requirements. Manufactured in China with guaranteed quality and new condition. Single port design for focused USB Type B connectivity.
Package suitable for assembly line insertion enhancing manufacturing efficiency. Explore additional Molex connectors and USB accessories in the EnvMart electronics components category to complete your project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates safely up to a maximum voltage of 30 volts.
It supports a current load of up to 1.8 amperes.
The connector is rated for operating temperatures between -30°C and 85°C.
It features a solder termination type, facilitating secure and durable connections on PCBs.
This connector has a right angle orientation, which helps optimize PCB space utilization.
The Molex 47346-1001 has a compact design with a single port.
It is constructed with copper alloy contacts, ensuring reliable electrical conductivity.
Yes, it is compliant with the USB 2.0 standard, ensuring broad compatibility.
This model features a surface mount design, which allows for easy soldering on PCB boards.
It is suitable for applications including computer peripherals, embedded systems, and industrial control units.
This connector is manufactured in China.
It belongs to the 4734 series, offering compatibility across Molex's USB connector range.
