Vishay 2.2 nF 760V AC ±20% Through Hole Multilayer Ceramic Capacitor VY1222M47Y5UQ63V0
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 760V ac |
| Brand | Vishay |
| Model | VY1222M47Y5UQ63V0 |
| Packaging | Bulk |
| Mount Type | Through Hole |
| Series | VY1 |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±20 % |
| Capacitance | 2.2nF |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | EN, REACH, RoHS, VDE, CSA, UL, IEC |
| Lead Diameter | 0.5mm |
| Dielectric | Y5U |
| Suppression Class | X1 |
| Lead Spacing | 10mm |
Key Features
- Built with Y5U dielectric material providing stable capacitance across operating conditions.
- Features a tolerance of ±20% ensuring reliable filtering and timing applications.
- Designed for through-hole mounting with a lead spacing of 10 mm for secure placement.
- Supplied in bulk packaging, suitable for volume manufacturing and assembly.
- Constructed with flame retardant epoxy resin encapsulation for enhanced safety.
- Lead diameter measures 0.5 mm made from tinned copper clad steel supports durability and conductivity.
- Operating temperature ranges from -40°C to a maximum of 125°C suitable for diverse environments.
- Conforms to multiple standards including EN, REACH, RoHS, VDE, CSA, UL, and IEC for quality assurance.
Product Description
Vishay VY1222M47Y5UQ63V0 is a high-reliability 2.2 nF multilayer ceramic capacitor rated at 760V AC, featuring a Y5U dielectric designed for effective noise suppression and across-the-line applications in industrial and electronic circuits.
The capacitor is fabricated with a ceramic disc silver plated on both sides, encapsulated with flame retardant epoxy resin to deliver superior safety and durability. Its leads are made of tinned copper clad steel with a diameter of 0.5 mm and a lead spacing of 10 mm to support stable through-hole mounting.
Operating within a temperature range of -40°C to 125°C, this capacitor ensures dependable performance in demanding conditions. It meets a variety of internationally recognized standards including EN, REACH, RoHS, VDE, CSA, UL, and IEC, verifying its compliance with stringent quality and environmental guidelines.
This model belongs to the VY1 series and features a suppression class X1, making it suitable for line bypass, antenna coupling, and across-the-line applications in electronics manufacturing, industrial machinery, automotive electronics, and HVAC systems.
Built with Y5U dielectric material providing stable capacitance across operating conditions. Features a tolerance of ±20% ensuring reliable filtering and timing applications. Designed for through-hole mounting with a 10 mm lead spacing for secure placement.
Supplied in bulk packaging, supporting large scale manufacturing processes. Encapsulated in flame retardant epoxy resin for enhanced safety during operation. Leads constructed from tinned copper clad steel ensure durability and conductivity.
Operating temperature range from -40°C up to 125°C for diverse industrial use. Complies with EN, REACH, RoHS, VDE, CSA, UL, and IEC standards. Suppression class X1 supports noise and transient voltage filtering applications.
This capacitor is optimized for use in industrial, electronic components manufacturing, and quality control systems. It’s particularly effective in automotive electronics, power supply design, and noise suppression applications involving high-voltage AC circuits.
Explore more high-quality Multilayer Ceramic Capacitors and electronic components in the Electronics & Electricals section at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 2.2 nF.
It is rated for 760V AC.
The capacitor features a tolerance of ±20%.
The operating temperature range is from -40°C to a maximum of 125°C.
It is constructed with Y5U dielectric material, which provides stable capacitance across operating conditions.
The lead diameter measures 0.5 mm.
The lead spacing is 10 mm, designed for secure placement during installation.
It conforms to several standards including EN, REACH, RoHS, VDE, CSA, UL, and IEC.
It is supplied in bulk packaging, suitable for volume manufacturing and assembly.
This model is suitable for line bypass, antenna coupling, and across-the-line applications in industrial and electronic circuits.
It belongs to the VY1 series, which is designed for effective noise suppression.
The suppression class is X1, making it suitable for noise and transient voltage filtering applications.
