Toshiba 4-Channel Non-Inverting Schmitt Trigger Input 3 State Quad Bus Buffer SOIC 14-Pin 2V to 6V 74HC125D

Free Delivery in India | Lowest Global Shipping Charges

Toshiba 4-Channel Non-Inverting Schmitt Trigger Input 3 State Quad Bus Buffer SOIC 14-Pin 2V to 6V 74HC125D

Name: Toshiba 4-Channel Non-Inverting Schmitt Trigger Input 3 State Quad Bus Buffer SOIC 14-Pin 2V to 6V 74HC125D
Brand: Toshiba
SKU: 150820
Price: 0.29 USD
Availability: InStock



Category Logic ICs Brand Toshiba Condition New

Specifications

Country of Origin	India
Brand	Toshiba
Height	1.38mm
Length	8.95mm
Model	74HC125D
Mount Type	Surface
Output type	3 State
Series	74HC
Input Type	Schmitt Trigger
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Number Of Channels	4
Pin Count	14
Maximum Supply Voltage	6V
Logic Family	74HC
Logic Function	Schmitt Trigger Buffer
Minimum Supply Voltage	2V
Maximum High Level Output Current	-7.8mA
Maximum Propagation Delay Time @ CL	150ns
Supply Current	40μA
Maximum Low Level Output Current	7.8mA
Balanced propagation delays	tPLH ≈ tPHL

Key Features

High-speed CMOS quad bus buffer fabricated with silicon gate CMOS technology.
Non-inverting Schmitt trigger input with 3-state output control.
Operates over a wide supply voltage range from 2 to 6 volts.
Low power dissipation ensuring energy efficiency.
Provides balanced propagation delays for reliable signal timing.
Includes protection circuits against static discharge and transient voltage.
Surface mount SOIC package with 14 pins for compact integration.
Maximum propagation delay time of 150 ns at specified load capacitance.

Product Description

Toshiba 74HC125D, model 74HC125D, is a 4-channel non-inverting Schmitt trigger input 3-state quad bus buffer in a 14-pin SOIC package, operating within a supply voltage range of 2 V to 6 V. This high-speed CMOS device is fabricated using silicon gate CMOS technology, combining fast operation with low power consumption, making it suitable for various industrial and electronic applications.

The device requires the control input G to be set high to place the output into a high impedance state, allowing flexible bus control. Its balanced propagation delays and low supply current consumption enhance signal integrity and reduce energy usage.

Equipped with protection circuits against static discharges and transient excess voltage, the 74HC125D is designed for robust and reliable operation within a temperature range of -40°C to 125°C. It offers a maximum propagation delay time of 150 nanoseconds under standard load conditions.

Its surface mount SOIC package with 14 pins supports efficient PCB layout for compact electronic designs. This quad bus buffer is ideal for applications demanding precise signal buffering, logic level shifting, and noise filtering.

High-speed CMOS fabrication with silicon gate technology. Non-inverting Schmitt trigger input providing stable signal transitions. 3-state output controlled via enable input. Wide operating voltage range from 2 V to 6 V.

Low power dissipation with maximum supply current of 40 μA. Balanced propagation delays ensuring timing accuracy. Static discharge and transient voltage protection on all inputs. Wide operating temperature for industrial use.

Compact 14-pin SOIC surface mount package. Reliable quad bus buffer suitable for semiconductor and electronics manufacturing.

This product is widely used in industrial equipment, embedded systems, communication devices, and other electronics requiring buffer and signal conditioning. Explore EnvMart for a broad range of semiconductor Logic ICs including buffers and bus transceivers.
