Nexperia CMOS Schmitt Trigger Input Inverter 6 Elements 14-Pin SO-8 Package 1.65-5.5V 74LVC14AD,118

Free Delivery in India | Lowest Global Shipping Charges

Nexperia CMOS Schmitt Trigger Input Inverter 6 Elements 14-Pin SO-8 Package 1.65-5.5V 74LVC14AD,118

Name: Nexperia CMOS Schmitt Trigger Input Inverter 6 Elements 14-Pin SO-8 Package 1.65-5.5V 74LVC14AD,118
Brand: Nexperia
SKU: 150462
Price: 0.17 USD
Availability: InStock



Category Inverters ICs Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1.45mm
Length	8.75mm
Model	74LVC14AD,118
Width	4mm
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVCMOS
Output type	Single Ended
Series	74LVC14A
Input Type	Schmitt Trigger
Maximum Operating Temperature	125°C
Package Type	SO-8
Minimum Operating Temperature	-40°C
Operating Voltage	1.65 to 5.5 V
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	3.6V
Logic Family	74LVC
Logic Function	Inverter Schmitt Trigger
Minimum Supply Voltage	1.2V
Maximum High Level Output Current	-24mA
Maximum Propagation Delay Time @ CL	9.5ns
Maximum Low Level Output Current	24mA

Key Features

Features Schmitt trigger inputs for enhanced noise immunity and signal conditioning.
Comes in a compact SO-8 surface mount package with 14 pins.
Supports wide operating temperature range from -40°C to 125°C.
Maximum propagation delay time is 9.5 nanoseconds at the specified load capacitance.
Inputs compatible with LVTTL/TTL logic levels; outputs are LVCMOS compatible.
Maximum supply voltage of 3.6 V with a minimum of 1.2 V.
Logic family belongs to the 74LVC series with 6 elements per chip.
Pin configuration and dimensions enable easy PCB integration and surface mount placement.

Product Description

Nexperia 74LVC14AD,118 is a high-performance CMOS Inverter IC featuring Schmitt trigger inputs. The device packs 6 inverter elements into a 14-pin SO-8 surface mount package and operates from 1.65 V to 5.5 V. It provides reliable signal conditioning due to its Schmitt trigger inputs, making it suitable for noise-sensitive applications.

This inverter series is part of the 74LVC logic family, compatible with LVTTL and TTL input logic levels and providing LVCMOS compatible outputs. The compact SO-8 package with a height of 1.45 mm, length of 8.75 mm, and width of 4 mm facilitates efficient PCB layout design in compact spaces.

The device supports a wide temperature range from -40°C to +125°C, making it suitable for harsh industrial and commercial environments. Its maximum propagation delay time is 9.5 ns, enabling fast switching capabilities in digital circuits.

Typical applications include signal debouncing, waveform shaping, and converting slow or noisy input signals into clean digital outputs. The device's maximum high-level output current is -24 mA, and maximum low-level output current is 24 mA, supporting a variety of driving loads.

Schmitt trigger input buffers for noise immunity and clean signal transitions. Surface mount SO-8 package for automated assembly. Wide supply voltage range of 1.65 to 5.5 V for flexible power management. High-speed operation with 9.5 ns max propagation delay time.

Wide operating temperature range suitable for industrial use. Compatible with standard logic families for easy integration. Compact dimensions tailored for space-saving applications.

This Nexperia inverter IC is ideal for electronic component manufacturing, semiconductor uses, embedded system designs, and digital logic systems where precise inverter functionality and signal integrity are required.
