Nexperia 30 V 200 mA Schottky Diode, Single, 3-Pin SOT-23 Package BAT54,235

Nexperia BAT54,235 Schottky Diode is a high-efficiency, single diode designed for surface mount applications in electronic circuits. It supports a maximum continuous forward current of 200 mA and a peak reverse repetitive voltage of 30 V, packaged in a compact 3-pin SOT-23 form factor measuring 3 mm length, 1.4 mm width, and 1 mm height. This diode is optimized for low forward voltage drop and high junction temperature operation, making it suitable for a wide range of industrial and automotive electronics applications.

The diode's ultra-small, low-profile surface-mount package lends itself to circuit designs where space-saving is critical. Its typical forward voltage of 800 mV and low capacitance results in negligible power switching losses, enhancing energy efficiency in power rectification and signal processing roles.

With a peak non-repetitive forward surge current of 600 mA and a sharp peak reverse recovery time of 5 ns, the BAT54,235 is capable of reliable high-speed switching. Operating temperature range from -55°C to 150°C ensures stability across demanding environmental conditions, extended further by its automotive standard AEC-Q101 qualification.

Common applications include usage in power supplies, voltage clamping, reverse polarity protection, and general-purpose rectification in industrial, automotive, and consumer electronics. Its robust characteristics make it a preferred component for designers aiming for efficient, reliable diode solutions in compact PCB layouts.

High efficiency with low forward voltage drop of 800 mV. Low capacitance and negligible power switching losses. Compact 3-pin SOT-23 surface-mount package. Temperature range from -55°C to 150°C with automotive AEC-Q101 standard compliance.

Peak non-repetitive forward surge current of 600 mA. Extremely fast 5 ns peak reverse recovery time. Low leakage current at 2 μA peak reverse current.

For designers and engineers seeking reliable Schottky diode components within compact footprints, the Nexperia BAT54,235 offers an excellent balance of performance, efficiency, and automotive-grade reliability. Browse EnvMart's catalog for this and other semiconductor components optimized for power and signal applications.
