Nexperia Schottky Diode 60 V 4.2 A Surface Mount SOD-128 PMEG6030EVPX
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG6030EVPX |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG6030EVP |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 4.2A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 300mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A |
| Maximum Forward Voltage Vf | 475mV |
| Peak Reverse Recovery Time trr | 20ns |
| Average forward current | IF(AV) ≤ 3 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- Offers maximum continuous forward current of 4.2 A for robust power handling.
- Peak reverse repetitive voltage of 60 volts suitable for various low voltage applications.
- Features low forward voltage drop of approximately 475 mV for energy efficient operation.
- Constructed with integrated guard ring providing stress protection and thermal reliability.
- Small form factor SOD-128 package supports compact PCB designs.
- Suitable for automotive industry applications with AEC-Q101 qualification.
- Wide operating temperature range from -55°C to 175°C enables operation in harsh environments.
- Fast switching speeds ensured by peak reverse recovery time of 20 ns.
Product Description
Nexperia PMEG6030EVPX Schottky Diode is a high performance semiconductor device tailored for efficient power management in electronic circuits. Featuring a maximum continuous forward current rating of 4.2 A and peak reverse repetitive voltage of 60 V, this diode provides reliable switching with minimal energy losses in compact surface-mount assemblies.
Encapsulated in a small footprint SOD-128 plastic package, the device integrates a guard ring for enhanced stress protection and clip-bonding technology to support high power capability. Its low forward voltage drop of approximately 475 mV contributes to improved energy efficiency, making it ideal for DC-to-DC converters, switch mode power supplies, and low power consumption electronics.
The diode operates across a wide temperature range from -55°C minimum to a maximum of 175°C, suitable for demanding automotive and industrial environments, complying with the AEC-Q101 automotive standard. Its fast recovery time of 20 nanoseconds enables rapid switching cycles, enhancing performance in high-frequency applications.
Applications for the Nexperia PMEG6030EVPX include reverse polarity protection, low voltage rectification, and general purpose switching in communications, industrial, automotive, and consumer electronic circuits. Its surface-mount design supports compact and space-saving PCB layouts, facilitating modern electronic product designs.
Maximum continuous forward current: 4.2 amperes. Peak reverse repetitive voltage: 60 volts. Low forward voltage drop approximately 475 millivolts. Small 2-pin SOD-128 package for surface mounting. Wide operating temperature range (-55°C to 175°C).
AEC-Q101 compliant for automotive applications. Fast switching with 20 ns peak reverse recovery time. Integrated guard ring for stress and thermal protection. Applications in DC-DC conversion, reverse polarity and power supplies.
Choose Nexperia Schottky Diodes for efficient, reliable power management in industrial, automotive, and electronic manufacturing sectors. Browse our extensive semiconductor and diode selections for your application on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 4.2 A.
This diode has a peak reverse repetitive voltage rating of 60 V.
The forward voltage drop is approximately 475 mV.
The dimensions of the SOD-128 package are 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
The operating temperature range is from -55°C to 175°C.
Yes, this model complies with the AEC-Q101 automotive standard, making it suitable for automotive applications.
The peak reverse recovery time is 20 ns.
This diode supports surface mounting.
The average forward current rating is IF(AV) ≤ 3 A.
It is suitable for applications such as DC-DC conversion, reverse polarity protection, and low voltage rectification.
The PMEG6030EVPX has a pin count of 2.
The peak non-repetitive forward surge current rating is 70 A.
