Wurth Elektronik 15μH ±20% 640mA Unshielded Surface Mount Inductor with Ferrite Core 3521 WE-PD2 7447732115
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | -40 °C to +125 °C |
| Height | 2.1mm |
| Length | 3.5mm |
| Depth | 3mm |
| Packaging | Tape & Reel |
| Series | WE-PD2 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | JEDEC JS709B, RoHS, REACH |
| Package/Case | 3521 |
| Maximum DC Current | 640mA |
| Pin Count | 2 |
| Maximum DC Resistance | 430mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 36MHz |
| Inductor Construction | Unshielded |
| Recommended solder profile | Reflow |
Key Features
- This surface mount inductor has a 3521 package/case with a length of 3.5mm, height of 2.1mm, and depth of 3mm.
- Constructed with a ferrite core material, providing excellent magnetic properties and low core losses.
- Inductor operates reliably in temperatures ranging from -40°C up to 125°C.
- Has a maximum DC resistance of 430mΩ and inductance tolerance of ±20%.
- Designed without shielding, suitable for applications requiring unshielded inductors.
- Comes in tape & reel packaging, optimized for automated surface mount assembly processes.
- Conforms to JEDEC JS709B standards and complies with RoHS and REACH regulations.
Product Description
Wurth Elektronik model 7447732115 is a 15μH ±20% unshielded surface mount inductor from the WE-PD2 series. Its ferrite core construction ensures magnetic stability and high performance in compact surface mount circuits. The 3521 package size (3.5mm length, 2.1mm height, and 3mm depth) allows integration into dense PCB layouts, supporting automated soldering via tape & reel packaging using reflow soldering profiles.
This component supports a maximum DC current of 640mA and has a low DC resistance of 430mΩ, facilitating efficient current flow with minimal energy loss. Rated for operation in a broad temperature range from -40°C to 125°C, it is ideal for industrial and commercial electronics applications that demand thermal and electrical reliability.
The inductor is unshielded, permitting optimal attenuation in MHz frequency ranges and is standardized to JEDEC JS709B, while meeting RoHS and REACH environmental compliance standards. Its core material is ferrite, which contributes to effective magnetic performance and durability.
Applications include switching regulators, embedded PC-Cards, graphic card power supplies, mainboards, and integrated DC/DC converters where reliable inductance and current capacity are critical to circuit functionality.
Compact 3521 surface mount package for space-efficient designs. Ferrite core provides magnetic stability and low core losses. Operational temperature from -40°C to +125°C enabling use in harsh environments. Maximum DC current rating of 640mA to handle moderate power loads.
Low resistance of 430mΩ reduces heat buildup during operation. Compliance with JEDEC JS709B, RoHS, and REACH ensures regulatory conformity. Packaging in tape & reel for streamlined automated assembly processes.
This Wurth Elektronik WE-PD2 7447732115 Surface Mount Inductor aids designers in achieving compact, efficient, and reliable power management circuits. Explore more components within our Electronics Components category at EnvMart to complement this inductor for your industrial, laboratory, or commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 15μH with an inductance tolerance of ±20%.
The maximum DC current rating for this inductor is 640mA, allowing it to handle moderate power loads efficiently.
The 3521 package has a length of 3.5mm, a height of 2.1mm, and a depth of 3mm, making it suitable for compact PCB layouts.
It operates reliably within a temperature range of -40°C to +125°C, making it suitable for various industrial applications.
The maximum DC resistance is 430mΩ, which helps reduce heat buildup during operation.
This inductor is constructed with a ferrite core material, providing excellent magnetic properties and low core losses.
This model is unshielded, allowing for optimal attenuation in MHz frequency ranges.
It is packaged in tape & reel format, which is optimized for automated surface mount assembly processes.
It conforms to JEDEC JS709B standards and complies with RoHS and REACH regulations.
The recommended solder profile for this inductor is reflow, suitable for surface mount applications.
This inductor is suitable for applications such as switching regulators, embedded PC-Cards, graphic card power supplies, and integrated DC/DC converters.
This inductor has a pin count of 2, facilitating easy integration into circuits.
