Samtec ERF8 Series Straight Surface PCB Socket 20-Contact 2 Row 0.8mm Pitch Solder
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 318V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 2.2A |
| Model | ERF8 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | ERF8 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Positions | Up to 200 |
| Pitch | 0.8mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Connector System | Board-to-Board |
| Stacking Height | 18mm |
| Row Pitch | 4.5mm |
| Stack Height | 7.00 mm - 16.00 mm |
Key Features
- Features a straight surface mount for easy PCB integration.
- Constructed with liquid crystal polymer housing for durability.
- Gold-plated bronze contacts provide excellent electrical conductivity and corrosion resistance.
- Supports a current rating of 2.2 A and voltage rating of 318 V.
- Operating temperature ranges from -55°C to 125°C, suitable for harsh environments.
- Stacking height measures 18 mm allowing flexible board configurations.
- Designed for high-speed signal transmission with Edge Rate® rugged contacts.
- Ideal for industrial, electronic, and communication equipment applications.
Product Description
Samtec ERF8 ERF8-010-05.0-S-DV-K-TR is a high-performance straight surface PCB socket designed for board-to-board connectivity in electronic components. The socket features 20 contacts arranged in 2 rows with a precise 0.8 mm pitch and a stacking height of 18 mm, making it suitable for compact and high-density PCB designs.
Its liquid crystal polymer housing ensures robust durability and stability during operation, while the bronze contacts plated with gold enhance conductivity and resist wear and corrosion for long service life. The socket is rated for a current of 2.2 A and voltage of 318 V, and operates efficiently within a wide temperature range from -55°C to 125°C.
The ERF8 series employs Edge Rate® rugged high-speed contact technology with smooth, broad milled contact surfaces that increase wear life and provide reliable signal integrity for high-speed electronic applications. It supports up to 200 positions and expertly facilitates complex board stacking configurations.
This product is dual sourced by Hirose®, reflecting industry-standard quality and availability. It is designed primarily for industrial electronics, telecommunications equipment, and other applications requiring rugged, dependable PCB connectors.
Features a straight surface mount design for easy PCB integration. Constructed with liquid crystal polymer housing for durability. Gold-plated bronze contacts ensure excellent electrical conductivity. Supports a current rating of 2.2 A and voltage rating of 318 V.
Operating temperature ranges from -55°C to 125°C. Stacking height of 18 mm for flexible board configurations. Utilizes Edge Rate® rugged contact technology for high-speed signal integrity. Dual sourced by Hirose® for quality assurance.
Suitable for industrial, laboratory, manufacturing, and telecom uses. Manufactured in the United States under strict standards. Explore our extensive selection of PCB Sockets and connectors at EnvMart for reliable performance in your electronic assemblies and projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 2.2 A and a voltage rating of 318 V.
The operating temperature ranges from -55°C to 125°C, making it suitable for harsh environments.
It features 20 contacts arranged in 2 rows with a pitch of 0.8 mm.
The housing is made of liquid crystal polymer, while the contacts are constructed from bronze and plated with gold for enhanced conductivity.
The stacking height measures 18 mm, allowing for flexible board configurations.
It employs Edge Rate® rugged contact technology, which provides high-speed signal integrity.
The socket uses solder termination type for secure connections.
This model supports up to 200 positions, facilitating complex board stacking configurations.
It is manufactured in the United States under strict standards.
The socket features a straight orientation for easy PCB integration.
It is designed primarily for industrial electronics, telecommunications equipment, and other applications requiring rugged PCB connectors.
The row pitch of this model is 4.5 mm, which is relevant for board design considerations.
