Molex PicoBlade Series Straight Through Hole PCB Header, 15 Contact, 1.25 mm Pitch, 1 Row, Shrouded 53047-1510
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | PicoBlade |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.3mm |
Key Features
- Compact 1.25 mm pitch design enables significant PCB space saving.
- 15 male contacts provide a secure electrical connection for up to 1 A current capacity.
- Shrouded housing made of durable nylon ensures protection and secure mating.
- Through hole mount provides reliable mechanical and electrical connection on PCBs.
- Friction locking mechanism prevents accidental unmating from vibration or mishandling.
- Contact material is phosphor bronze with tin plating for corrosion resistance.
- Operates safely within -40°C to 85°C temperature range.
- Tail pin length of 2.3 mm ensures proper soldering and retention.
Product Description
Molex 53047-1510 is a PicoBlade Series PCB Header featuring a straight through hole, shrouded single-row design with 15 male contacts spaced at a 1.25 mm pitch. It provides a compact and reliable wire-to-board interconnection system with a current rating of 1 A and voltage rating of 125 V.
Constructed with a nylon housing, this connector ensures durability and secure mating via a friction locking mechanism that minimizes accidental disconnections due to vibration or mishandling. The phosphor bronze contacts plated with tin deliver consistent electrical performance.
The through hole mount design offers excellent mechanical retention and adaptability to PCB manufacturing processes. Tail pin length of 2.3 mm facilitates secure solder joints and stress relief.
This connector operates reliably within a temperature range of -40°C to 85°C, making it suitable for use in demanding industrial and electronic applications including automotive alarm systems, industrial control equipment, medical devices, and consumer electronics such as DVD players and car audio.
The PicoBlade connector system enables up to 45% space savings on PCBs compared to traditional 2.00 mm pitch connectors while maintaining equivalent current handling. Compact 1.25 mm pitch reduces PCB footprint significantly.
Friction locking housing prevents accidental unmating. Durable nylon housing with shrouded design for contact protection. Phosphor bronze contacts with tin plating ensure corrosion resistance and reliable conductivity. Suitable for automotive, industrial, medical, and consumer electronic applications.
Wide operating temperature range supports harsh environments. Tail pins optimize solder joint strength and strain relief. Manufactured in Japan to strict quality standards. Single row, 15 contact configuration offers flexible wiring options.
Explore more PCB Headers and electronic components from Molex on EnvMart to fulfill your industrial and electronic design requirements.
