Wurth Elektronik 1327 Series PCB Terminal Block 3-Contact 5 mm Pitch Through Hole 1 Row 691132700003

Wurth Elektronik 691132700003 PCB Terminal Block 3-Contact 5 mm Pitch Through Hole 1 Row is a high quality PCB mount terminal block designed to facilitate secure and reliable electrical connections on printed circuit boards. Featuring 3 contacts arranged in a single row with 5 mm pitch, this terminal block is ideal for applications requiring compact, vertical wire entry.

This terminal block utilizes a pressure clamp system operated by M2.5 screws, combined with zinc plated steel clamps, to ensure a firm mechanical and electrical connection to solid or stranded wires. It supports a wide range of wire sizes from 30 AWG (0.05 mm²) up to 12 AWG (3.31 mm²), rated for electrical currents up to 22 A and voltages up to 450 V AC, making it suitable for a variety of industrial, electronics manufacturing, and power distribution uses.

The housing is crafted from UL94-V0 rated grey polycarbonate, ensuring excellent fire resistance and durability under demanding conditions. The compact dimensions of 15 mm length, 15.5 mm width, and 10.5 mm depth facilitate easy integration on densely populated PCBs. Designed and manufactured in Hungary, this terminal block complies with international standards including cULus, RoHS, and VDE, ensuring quality and compliance for professional electronics assembly.

Supports 3 electrical contacts for versatile PCB connections. Features a 5 mm pitch spacing between contacts for compact installation. Wires can be secured via through hole mount using M2.5 screws and zinc plated steel clamps.

Accepts wire sizes from 30 AWG to 12 AWG, with cross sections between 0.05 mm² and 3.31 mm². Rated for 22 A current and 450 V AC voltage operation. Constructed with grey UL94-V0 polycarbonate housing ensuring fire retardance and durability.

Measuring 15 mm length, 15.5 mm width, and 10.5 mm depth for compact PCB integration. Manufactured in Hungary meeting cULus, RoHS, and VDE standards.

This product is suitable for applications in industrial electronics, power supply systems, control panel manufacturing, and other sectors requiring robust PCB terminal connections. Users can rely on the quality and compliance certifications to meet stringent safety and performance requirements.

Explore more from the Wurth Elektronik 1327 series and find compatible components to optimize your electronic assemblies through EnvMart’s comprehensive catalog.
