STMicroelectronics PNP Darlington Transistor 10 A 100 V, HFE 500, 3-Pin TO-247 TIP147

STMicroelectronics TIP147 is a PNP Darlington Transistor designed for high current and voltage switching applications, combining a maximum continuous collector current of 10 A and a collector emitter voltage of 100 V. This transistor delivers a minimum DC current gain of 500, making it suitable for signal amplification and high power control in industrial, commercial, and electronic equipment.

The device comes in a TO-247 3-pin through-hole package, facilitating robust mounting and dissipation of the maximum power of 125 W. It supports operating temperatures from -65°C up to 150°C, enabling reliable performance in demanding environments such as industrial automation, power supplies, and motor control circuits.

Featuring a maximum collector emitter saturation voltage of 2 V and maximum emitter base voltage of 5 V, TIP147 allows efficient switching with minimal losses. It has one transistor element per chip with PNP polarity, supporting complementary transistor circuit designs.

The compact dimension of the transistor, measuring 20.15 mm in height and 15.75 mm in length, fits standard PCB layouts and power assembly requirements. High current handling capacity for robust power applications. Excellent voltage ratings for versatile electrical integration.

High current gain ensures effective amplification performance. To-247 package supports enhanced thermal management. Wide operating temperature range for use in harsh conditions. Designed for industrial, electronic, and commercial power control uses.

This transistor is an essential component for engineers designing circuits requiring durable and efficient power switching solutions. Explore similar products and detailed technical documents to integrate the TIP147 successfully into your projects with confidence.
