TDK Shielded Wirewound Surface Mount Inductor with Metallic Magnetic Core 2.2 μH ±20 % 8.4 A Idc SPM6530T-2R2M

The TDK SPM6530T-2R2M is a shielded wirewound Surface Mount Inductor featuring a metallic magnetic core delivering an inductance of 2.2 μH with a tolerance of ±20%. Designed for power circuit applications, this inductor supports a maximum DC current of 8.4 A, making it suitable for handling significant current loads.

The device comes in a 6530 package size, measuring 7.1 mm in length, 6.5 mm in depth, and 3 mm in height. It is supplied in tape and reel packaging optimal for automated PCB assembly processes. Its operating temperature range spans from -40°C to 125°C, supporting a broad spectrum of industrial and commercial environments.

Magnetic shielding is integrated to reduce electromagnetic interference, enhancing circuit reliability. The inductor's wirewound construction with an integrated molded coil significantly reduces hum noise compared to core adhesive coils, crucial for noise-sensitive applications.

With a low DC resistance of 19 milliohms, the inductor ensures efficient power management and minimal losses. The solder termination style guarantees secure mounting to printed circuit boards. Designed to meet RoHS standards, the TDK SPM6530T-2R2M supports environmentally responsible manufacturing practices.

This inductor finds application in electronic components, power supplies, and other industrial circuits requiring reliable inductance with high current capability and compact surface mount design. Industrial sectors such as telecommunications, automotive electronics, consumer electronics, and power management benefit from its robust performance.

The inductor features a metallic magnetic core for improved magnetic performance. It has a ±20% inductance tolerance ensuring reliable performance in circuits. Surface mount package size is 6530 with tape and reel packaging for automated assembly.

The component supports operating temperatures from -40°C to 125°C for wide application range. The device includes magnetic shielding to minimize electromagnetic interference. Designed with solder termination style for secure PCB mounting.

The inductor construction is wirewound and integrated molded for low noise. Maximum DC resistance is 19 milliohms contributing to efficient operation. Pin count is 2, compatible with surface mount assembly standards. Explore TDK inductors and related surface mount components in the Electronics & Electricals category on EnvMart for high-quality industrial and electronic circuit solutions.
