DiodesZetex 1.12 V Zener Diode Single 200 mW 5% Tolerance 2-Pin Surface Mount SOD-323 DDZ9699S-7

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 1.12 V Zener Diode Single 200 mW 5% Tolerance 2-Pin Surface Mount SOD-323 DDZ9699S-7

Name: DiodesZetex 1.12 V Zener Diode Single 200 mW 5% Tolerance 2-Pin Surface Mount SOD-323 DDZ9699S-7
Brand: DiodesZetex
SKU: 133503
Price: 0.08 USD
Availability: InStock



Category Zener Diodes Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	1.1mm
Length	1.8mm
Model	DDZ9699S-7
Mount Type	Surface
Series	DDZ9699S
Maximum Operating Temperature	150°C
Package Type	SOD-323
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	200mW
Diode Configuration	Single
Test Current It	0.05mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	12V
Zener Type	General Purpose
Surface Mount case	SOD-323 (SC-76)
Diodes Inc, 24V Zener Diode 2.5% 500 mW SMT 2-Pin SOD-323FBrand	DiodesZetex

Key Features

Nominal Zener voltage of 12 V ensures accurate voltage stabilization.
Maximum power dissipation of 200 mW supports small-scale power applications.
Compact surface mount design with SOD-323 package for efficient PCB layout.
Low test current of 0.05 mA and minimal reverse leakage current of 50 nA enhances performance.
Operating temperature range from -65°C to 150°C ensures wide environmental compatibility.
Tight tolerance of ±5% maintains consistent voltage regulation.
Two-pin configuration compatible with various electronic assemblies.
RoHS compliant ensuring environmentally safe manufacturing standards.

Product Description

DiodesZetex DDZ9699S-7 is a high-quality 1.12 V single Zener diode designed for voltage regulation in sensitive electronic circuits. Its nominal Zener voltage of 12 V combined with a maximum power dissipation rating of 200 mW makes it ideal for protective applications in low power environments.

The diode features a surface mount SOD-323 package with a compact 1.8 mm length and 1.1 mm height, making it suitable for space-conscious PCB designs. With a low test current of 0.05 mA and maximum reverse leakage current of only 50 nA, this diode provides reliable voltage stabilization with minimal losses.

Designed to operate in a broad temperature range from -65°C to 150°C, it supports usage in harsh industrial and automotive environments. This component is RoHS compliant and categorized as a general purpose Zener diode, supporting versatile electrical and electronic assembly needs.

Its 2-pin configuration is compatible with standard PCB setups, ensuring easy integration into various power and semiconductor circuits. Nominal Zener voltage 12 V with ±5% tolerance for consistent voltage regulation. Maximum power dissipation 200 mW suitable for low power electronic applications.

Surface mount SOD-323 (SC-76) package dimensions: 1.8 mm length, 1.1 mm height. Low test current of 0.05 mA and low reverse leakage current of 50 nA enhances efficiency. Wide temperature range from -65°C to 150°C for robust operation.

RoHS compliant ensuring environmentally friendly manufacturing. General purpose Zener diode type for versatile application. 2-pin arrangement compatible with standard surface mount designs.

This Zener diode is widely used in industrial electronics, semiconductor circuits, power supplies, and voltage regulation modules, ensuring stable operations under variable electrical conditions.
