| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | DDZ9689S-7 |
| Mount Type | Surface |
| Series | DDZ |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Test Current It | 0.05mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 5.1V |
| Zener Type | General Purpose |
| Surface Mount case | SOD-323 (SC-76) |
DiodesZetex DDZ9689S-7 is a surface mount general purpose Zener diode designed for precision voltage regulation and protection applications. It has a nominal Zener voltage of 5.1 V and a maximum power dissipation of 200 mW, making it suitable for low power electronic circuits requiring stable reference voltages or clamping functions.
This diode features a compact 2-pin SOD-323 package measuring 1.8 mm in length and 1.1 mm in height, optimized for efficient PCB layout in modern electronics manufacturing. It operates effectively over a wide temperature range from -65°C to 150°C, supporting reliable performance in industrial, commercial, and consumer electronics environments.
The device has a tight voltage tolerance of ±5% and a low maximum reverse leakage current of 5 μA, contributing to energy efficient and accurate operation. Its test current of 0.05 mA ensures that the electrical parameters meet rigorous quality standards.
Compliant with RoHS European environmental directives, this Zener diode supports sustainable manufacturing practices. Applications include voltage regulation, signal conditioning, and protection circuits in power supplies, instrumentation, automotive electronics, and communication devices.
This diode offers tight voltage tolerance of ±5% for precise voltage regulation. Maximum power dissipation is rated at 200 mW to ensure reliable operation. It features a maximum reverse leakage current of 5 μA for efficiency.
Operates reliably within a wide temperature range from -65°C to 150°C. Small form factor with 1.8 mm length and 1.1 mm height suits compact PCB designs. Test current is 0.05 mA for quality assurance of electrical characteristics.
Compliant with RoHS standards ensuring environmental safety. Typical applications include voltage regulation and overvoltage protection in electronic circuits. Explore more DiodesZetex products in the Zener Diodes category at EnvMart for all your semiconductor component needs.
