Nexperia Non-Inverting Open Drain Buffer 5-Pin SC-74 1.65 to 5.5 V Supply 32 mA Output Current 74LVC1G07GV,125

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Non-Inverting Open Drain Buffer 5-Pin SC-74 1.65 to 5.5 V Supply 32 mA Output Current 74LVC1G07GV,125

Name: Nexperia Non-Inverting Open Drain Buffer 5-Pin SC-74 1.65 to 5.5 V Supply 32 mA Output Current 74LVC1G07GV,125
Brand: Nexperia
SKU: 133206
Price: 0.1 USD
Availability: InStock



Category Logic ICs Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	3.1mm
Model	74LVC1G07GV,125
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVCMOS
Output type	Open Drain
Series	74LVC1G07
Input Type	Single Ended
Maximum Operating Temperature	125°C
Package Type	SC-74
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Number Of Channels	1
Operating Voltage	1.65 to 5.5 V
Pin Count	5
Maximum Supply Voltage	5.5V
Logic Family	LVC
Logic Function	Buffer
Minimum Supply Voltage	1.65V
Maximum Propagation Delay Time @ CL	8.4ns
Supply Current	100mA
Maximum Low Level Output Current	32mA

Key Features

This buffer IC features non-inverting open drain output for versatile logic interfacing.
It has a 5-pin SC-74 package with a compact length of 3.1 mm and height of 1 mm.
The device supports a maximum propagation delay of 8.4 ns at specified load capacitance.
Operating temperature range from -40 °C to 125 °C ensures robustness in various environments.
The IC is compatible with input LVTTL/TTL logic levels and output LVCMOS levels.
It has a supply current of approximately 100 mA and supports a maximum low-level output current of 32 mA.
This device is a member of the 74LVC family of low-voltage CMOS logic inverters and buffers.
The product is surface-mountable, facilitating automated PCB assembly.

Product Description

The Nexperia 74LVC1G07GV,125 Non-Inverting Open Drain Buffer is a single-channel logic IC designed for efficient buffering in digital circuits. Packaged in a compact 5-pin SC-74 surface mount package measuring 3.1 mm in length and 1 mm in height, it offers a small form factor suitable for space-constrained applications.

Operating over a wide supply voltage range from 1.65 V to 5.5 V, it is optimized for low-voltage CMOS logic circuits and compatible with both LVTTL/TTL inputs and LVCMOS outputs. This versatility makes it ideal for interfacing between different logic families in microcontroller, FPGA, and ASIC designs.

The device provides non-inverting open drain output, enabling wired-AND connections and flexible logic signal control. It supports a maximum propagation delay of 8.4 ns at typical loads, providing fast signal buffering for high-speed digital systems.

Designed to work comfortably in challenging thermal environments, it operates reliably across temperatures from -40 °C to +125 °C. The maximum low-level output current rating of 32 mA supports driving a variety of loads while maintaining signal integrity.

Its 74LVC1G07 series design integrates low-voltage CMOS technology to offer improved power efficiency and faster switching speeds compared to traditional logic families. The supply current is typically around 100 mA, facilitating energy-conscious designs.

Applications for the 74LVC1G07GV,125 include industrial automation, consumer electronics, communication equipment, and embedded system logic buffering. The surface mount format simplifies assembly and enables mass production on automated PCB lines.

This buffer is ideal for enhancing digital signal integrity in industrial, commercial, and embedded electronics. It supports interface bridging between TTL and CMOS logic levels. Its open drain output allows multiple outputs to be connected safely for wired logic operations.

The device's robust thermal and electrical characteristics suit it for high-reliability applications. Compact packaging supports miniaturized electronic device designs. Explore the full range of Nexperia Logic ICs and buffers at EnvMart to find compatible components for your circuit designs and manufacturing needs.
