| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 3mm |
| Model | BZX84B5V1-7-F |
| Mount Type | Surface |
| Series | BZX84B5V1 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 350mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 2μA |
| Nominal Zener Voltage Vz | 5.1V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 60Ω |
| Typical Voltage Temperature Coefficient | -2.7mV/°C |
| Surface Mount case | SOT-23 |
DiodesZetex BZX84B5V1-7-F is a high-quality single element Zener diode designed for voltage regulation in electronic circuits. Featuring a nominal Zener voltage of 5.1 V and a maximum power dissipation of 350 mW, it provides precise voltage stabilization suitable for various industrial and automotive applications.
This diode comes in a compact SOT-23 surface mount package with three pins, enabling easy and efficient PCB layout integration. It supports operation in a broad temperature range from -65°C up to 150°C, making it highly reliable for harsh operating environments.
The device exhibits a maximum reverse leakage current of only 2 microamperes, maintaining low leakage and power loss. The maximum Zener impedance is rated at 60 ohms, contributing to stable voltage regulation at the test current of 5 mA. Its voltage temperature coefficient of -2.7 mV/°C ensures consistent performance despite changes in temperature.
Automotive grade AEC-Q101 qualification guarantees compliance with demanding automotive industry standards, ensuring durability and long-term performance in automotive electronics systems.
Typical uses include voltage clamping, voltage regulation, waveform clipping, and protecting sensitive semiconductor components in consumer electronics, industrial controls, laboratory instruments, and automotive electronics.
Nominal zener voltage of 5.1 V with 2% tolerance for precise voltage regulation. Compact SOT-23 surface mount package for space-constrained PCB designs. Low maximum reverse leakage current of 2 µA reduces power loss. Wide operating temperature range from -65°C to 150°C suitable for harsh environments.
Maximum power dissipation rating of 350 mW supports reliable low power operation. Voltage temperature coefficient of -2.7 mV/°C ensures temperature stability. Automotive AEC-Q101 qualification for high-reliability applications.
Ideal for industrial, automotive, laboratory, and electronic assembly applications. 3-pin configuration enables simple PCB mounting and electrical connection. Explore a range of Zener Diodes and related semiconductor components in EnvMart for your precise engineering requirements.
