Vishay 2525 Shielded Surface Mount Inductor with Powdered Iron Core 4.7μH ±20% 6A IDC IHLP2525CZER4R7M11
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 3mm |
| Length | 6.86mm |
| Model | IHLP2525CZER4R7M11 |
| Depth | 6.47mm |
| Series | IHLP-2525CZ-11 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Powdered Iron |
| Inductance | 4.7μH |
| Standards/Approvals | RoHS, JEDEC |
| Package/Case | 2525 |
| Maximum DC Current | 6A |
| Maximum DC Resistance | 33.4mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 1MHz |
| Inductor Construction | Shielded |
Key Features
- Designed with a powdered iron core providing stable magnetic properties.
- Shielded construction minimizes electromagnetic interference.
- Compact 2525 package with dimensions 6.86mm length and 6.47mm depth.
- Operates reliably from -55°C to 125°C temperature range.
- Offers low maximum DC resistance of 33.4mΩ.
- Maximum self-resonant frequency of 1MHz ensures suitability for high-frequency applications.
- Surface mount termination style allows easy PCB assembly.
- RoHS and JEDEC compliant meeting industry environmental and quality standards.
Product Description
Vishay IHLP2525CZER4R7M11 is a high current, low profile Surface Mount Inductor designed for demanding electronic applications. This shielded inductor utilizes a powdered iron core to provide stable inductance and low noise operation, making it ideal for sensitive circuits.
The compact 2525 package measures 6.86mm in length, 6.47mm in depth, and 3mm in height, offering a space-saving solution for PCB layouts requiring high current handling. It supports a maximum DC current of 6A, has a low DC resistance of 33.4mΩ, and operates efficiently across a broad temperature range from -55°C to 125°C.
This inductor has a maximum self-resonant frequency of 1MHz, enabling its use in power supplies, DC/DC converters, and other high-frequency applications commonly found in portable devices, computing equipment, and industrial electronics.
Its shielded magnetic construction minimizes electromagnetic interference and buzz noise, improving signal integrity in complex systems. Applications include power management for notebooks, desktops, servers, and various battery-powered electronics where high performance and reliability are essential.
Powdered iron core construction ensures stable noise-free inductance. Shielding reduces electromagnetic interference for cleaner signal performance. Compact 2525 surface mount package suitable for dense PCB layouts. Wide operating temperature range supports industrial and commercial environments.
Low DC resistance maximizes efficiency in power applications. Compliance with RoHS and JEDEC standards guarantees quality and environmental safety. High current rating supports transient current spikes without saturation.
Ideal for power supplies, DC/DC converters, and field programmable gate arrays (FPGA).
Explore Vishay inductors in the Electronics Components category on EnvMart for reliable, high-quality passive components intended for various industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 4.7μH with a tolerance of ±20%.
It supports a maximum DC current of 6A, making it suitable for high current applications.
This unit has dimensions of 6.86mm in length, 6.47mm in depth, and a height of 3mm.
It operates reliably within a temperature range of -55°C to 125°C.
The inductor utilizes a powdered iron core, which provides stable magnetic properties.
The maximum self-resonant frequency is 1MHz, suitable for high-frequency applications.
It features a surface mount termination style, allowing for easy PCB assembly.
This model is compliant with RoHS and JEDEC standards, ensuring environmental safety and quality.
The shielded construction minimizes electromagnetic interference, improving signal integrity in circuits.
The maximum DC resistance is 33.4mΩ, which helps maximize efficiency in power applications.
This inductor is part of the IHLP-2525CZ-11 series.
