Vishay 2525 Shielded Surface Mount Inductor Metal Composite Core 3.3 μH ±20% 6 A IHLP2525CZER3R3M01
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 3mm |
| Length | 6.86mm |
| Model | IHLP2525CZER3R3M01 |
| Depth | 6.47mm |
| Series | IHLP-2525CZ-01 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 3.3μH |
| Standards/Approvals | JEDEC, RoHS |
| Package/Case | 2525 |
| Maximum DC Current | 6A |
| Maximum DC Resistance | 30mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Shielded |
Key Features
- High current low profile magnetically shielded inductor suitable for compact applications.
- Inductance tolerance of ±20% ensures reliable performance.
- Maximum DC resistance of 30 mΩ minimizes power loss.
- Operating temperature range from -55°C to 125°C for versatile use.
- Constructed with metal composite core for enhanced magnetic shielding.
- Maximum self-resonant frequency up to 5 MHz for high frequency applications.
- Moulded body and JEDEC, RoHS compliant standards ensure durability and environmental compliance.
- Ideal for use in PDAs, notebooks, servers, high current POL converters, and DC/DC power supplies.
Product Description
Vishay IHLP2525CZER3R3M01 is a 2525 shielded Surface Mount Inductor featuring a metal composite core, designed to provide a 3.3 μH inductance value with a ±20% tolerance and a maximum DC current rating of 6 A. This inductor is engineered to handle high transient current spikes without saturation, made possible by its composite construction that also reduces audible buzz noise.
The inductor dimensions are compact with a length of 6.86 mm, height of 3 mm, and a depth of 6.47 mm, employing a surface mount termination style suited for easy mounting on printed circuit boards. This low profile component supports a maximum self-resonant frequency of 5 MHz, making it ideal for high frequency circuit designs.
The device operates reliably within a temperature range from -55°C to 125°C, supporting demanding electronic applications. It is fully moulded and complies with JEDEC and RoHS standards, reflecting its high manufacturing quality and environmental safety.
Applications include integration in portable electronic devices such as PDAs, notebooks, desktop computers, and servers requiring high current POL converters and low profile power supplies. It is also suitable for systems requiring DC/DC conversion at distributed power stages and FPGA power management solutions.
High current, low profile magnetically shielded wire wound choke offers excellent performance in compact spaces. Metal composite core construction provides robustness and minimizes electromagnetic interference. Designed for high frequency operation up to 5 MHz with low DC resistance of 30 mΩ.
Wide temperature operation range from -55°C to 125°C for various environmental conditions. Manufactured to JEDEC and RoHS compliances, ensuring quality and eco-friendliness. Surface mount termination style facilitates automated PCB assembly and compact device design.
Ideal for portable and distributed power applications requiring stable inductance and high current handling. Explore Vishay products at EnvMart for advanced electronic components engineered for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 3.3 μH with a tolerance of ±20%.
The maximum DC current rating for this inductor is 6 A.
It has a maximum self-resonant frequency of up to 5 MHz, suitable for high frequency applications.
The dimensions of this unit are 6.86 mm in length, 6.47 mm in depth, and 3 mm in height.
It operates reliably within a temperature range of -55°C to 125°C.
This inductor is constructed with a metal composite core, enhancing its magnetic shielding.
It complies with JEDEC and RoHS standards, ensuring quality and environmental safety.
The maximum DC resistance is 30 mΩ, which helps minimize power loss.
This model features a surface mount termination style, facilitating easy mounting on printed circuit boards.
It is suitable for use in PDAs, notebooks, servers, high current POL converters, and DC/DC power supplies.
The inductor is shielded, designed to reduce electromagnetic interference and audible buzz noise.
This inductor belongs to the IHLP-2525CZ-01 series.
