Vishay 2525 Shielded Surface Mount Inductor Metal Composite Core 150nH ±20% 26A IHLP2525CZERR15M01

Vishay IHLP2525CZERR15M01 2525 shielded surface mount inductor offers a compact and high-performance solution for modern electronic applications requiring low profile and high current handling capacity. Designed with a metal composite core, this inductor provides stable inductance of 150 nanohenries with a tolerance of ±20% and supports a maximum DC current rating of 26 amperes.

The IHLP-2525CZ-01 series is magnetically shielded, which significantly reduces electromagnetic interference (EMI) and minimizes noise, making it ideal for sensitive electronic circuits. Its low DC resistance of 2.5 milliohms contributes to high efficiency and reduced power losses.

Measuring 6.86mm in length, 6.47mm in depth, and 3mm in height, the compact 2525 package fits well in tight PCB layouts, especially suited for consumer electronics such as PDAs, notebooks, desktop and server devices where space and power efficiency are critical.

This surface mount inductor is designed to operate reliably across a wide temperature range from -55°C to 125°C, making it suitable for automotive, industrial, and commercial electronic applications.

Typical applications include low profile, high current power supplies, DC/DC converters in distributed power systems, and field programmable gate array (FPGA) power regulation. Its shielded wire-wound construction ensures ultra-low buzz noise even during transient current spikes.

High current low profile shielded design to minimize EMI interference. Inductance of 150nH with ±20% tolerance for precise filtering. Maximum DC current rating of 26A enables high power handling. Low DC resistance of 2.5mΩ reduces energy loss and heat generation.

Compact 2525 package dimensions for space-constrained PCB applications. Wide operating temperature range from -55°C to 125°C for harsh environments. Metal composite core enables stability and low acoustic noise. Complies with JEDEC and RoHS environmental and quality standards.

Ideal for power converters, battery powered devices, and embedded systems.

Choose Vishay’s IHLP2525CZERR15M01 shielded Surface Mount Inductor for efficient, reliable, and compact inductive components in industrial, laboratory, manufacturing, and commercial electronic systems. Explore our extensive range of power inductors and related components on EnvMart to suit all your electronic circuit needs.
