Vishay 2525 Shielded Surface Mount Inductor, Metal Composite Core, 820 nH ±20% Inductance, 13 A DC Current IHLP2525CZERR82M01
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 3mm |
| Length | 6.86mm |
| Model | IHLP2525CZERR82M01 |
| Depth | 6.47mm |
| Series | IHLP-2525CZ-01 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 820nH |
| Standards/Approvals | RoHS, JEDEC |
| Package/Case | 2525 |
| Maximum DC Current | 13A |
| Maximum DC Resistance | 8mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Shielded |
Key Features
- High current shielded surface mount inductor for electronic applications.
- Operates with ultra low DC resistance of 8 mΩ for efficient performance.
- Designed to handle transient current spikes without saturation.
- Composite construction reduces buzz noise in operation.
- Suitable for frequency ranges up to 5 MHz, ensuring versatile use.
- Wide operating temperature range from -55°C to 125°C for durability.
- Compact 2525 package size with dimensions 6.86mm length, 6.47mm depth, and 3mm height.
Product Description
Vishay IHLP2525CZERR82M01 is a 2525 shielded surface mount inductor featuring a metal composite core. This high current low profile inductor provides an inductance value of 820 nH with a tolerance of ±20%, supporting maximum DC currents up to 13 A. Its design incorporates a shielded construction which helps in minimizing electromagnetic interference and ensures effective performance in sensitive electronic circuits.
The inductor exhibits a very low DC resistance of 8 milliohms, contributing to high efficiency in power regulation applications. It operates reliably over a wide temperature range from -55°C to 125°C, making it suitable for demanding environments. The inductor supports a maximum self-resonant frequency of 5 MHz, expanding its use in high frequency power conversion and filtering systems.
With compact dimensions of 6.86 mm length, 6.47 mm depth, and 3 mm height, the component fits well into compact PCB layouts. Its surface mount termination style allows easy assembly onto printed circuit boards, making it ideal for automated manufacturing processes.
This Vishay IHLP2525CZERR82M01 series inductor is well-suited for industrial, computing, telecommunications, automotive electronics, and power management applications. Typical uses include POL converters, low profile high current power supplies, DC/DC converters, and battery powered devices requiring efficient transient spike handling and noise reduction.
High current shielded surface mount inductor for electronic applications. Operates with ultra low DC resistance of 8 mΩ for efficient performance. Designed to handle transient current spikes without saturation. Composite construction reduces buzz noise in operation.
Suitable for frequency ranges up to 5 MHz, ensuring versatile use. Wide operating temperature range from -55°C to 125°C for durability. Compact 2525 package size with dimensions 6.86mm length, 6.47mm depth, and 3mm height.
This product is RoHS and JEDEC compliant, reflecting adherence to industry standards for safety and quality assurance.
Explore more Vishay Surface Mount Inductors and other electronic components in the Electronics & Electricals category at EnvMart for reliable industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay IHLP2525CZERR82M01 has an inductance value of 820 nH with a tolerance of ±20%.
It can handle a maximum DC current of 13 A.
The dimensions of the 2525 package are 6.86 mm in length, 6.47 mm in depth, and 3 mm in height.
The maximum self-resonant frequency is 5 MHz, making it suitable for high frequency applications.
It operates over a wide temperature range from -55°C to 125°C.
The inductor features a metal composite core, which helps in reducing buzz noise during operation.
The inductor has a very low DC resistance of 8 mΩ, contributing to its efficiency.
It uses a surface mount termination style, allowing for easy assembly onto printed circuit boards.
Yes, it is RoHS and JEDEC compliant, reflecting adherence to industry standards for safety and quality assurance.
It is well-suited for applications in industrial, computing, telecommunications, automotive electronics, and power management.
The shielded construction minimizes electromagnetic interference, ensuring effective performance in sensitive electronic circuits.
This inductor belongs to the IHLP-2525CZ-01 series.
