Vishay 5050 Shielded Surface Mount Inductor with Metal Composite Core 10 μH ±20 %, 10 A Idc IHLP5050FDER100M01
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 6.5mm |
| Length | 13.2mm |
| Model | IHLP5050FDER100M01 |
| Depth | 12.9mm |
| Packaging | Reel |
| Series | IHLP-5050FD-01 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | 5050 |
| Maximum DC Current | 10A |
| Maximum DC Resistance | 17.2mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5MHz |
| Inductor Construction | Shielded |
Key Features
- Features a metal composite core for enhanced magnetic properties.
- Compact 5050 package measuring 13.2 mm length, 6.5 mm height, and 12.9 mm depth.
- Shielded construction reduces noise and electromagnetic interference.
- Suitable for high current POL converters and low profile power supplies.
- Operates reliably within the temperature range of -55°C to 125°C.
- Maximum DC resistance of 17.2 mΩ ensures efficient operation.
- RoHS compliant ensuring environmentally safe manufacturing standards.
- Supports frequencies up to 5 MHz with high transient current spike tolerance.
Product Description
Vishay IHLP5050FDER100M01 is a 5050 shielded surface mount inductor featuring a metal composite core, providing 10 μH inductance with a ±20 % tolerance and a maximum DC current of 10 A. Designed with low profile and shielded construction, this inductor efficiently minimizes electromagnetic interference and noise, ideal for advanced electronic designs requiring robust inductive components.
The inductor package measures 13.2 mm in length, 6.5 mm in height, and 12.9 mm in depth, fitting compact PCB layouts while maintaining high electrical performance. Its maximum DC resistance of 17.2 mΩ ensures minimal power loss during operation, enhancing overall circuit efficiency.
Built for resilience, the IHLP5050FDER100M01 performs reliably over a wide temperature range from -55°C to 125°C, making it suitable for demanding industrial and commercial applications including PDA, notebook, desktop, and server devices. Its capability to handle high transient current spikes without saturation is supported by its composite construction.
Typical applications encompass high current POL converters, battery-powered devices, low profile power supplies, and DC/DC converters used in distributed power systems and Field Programmable Gate Arrays (FPGA). The inductor’s shielding supports high frequency operation up to 5 MHz, further expanding its versatility.
Features a metal composite core for optimal magnetic performance. Shielded wire wound choke construction reduces buzz noise. Surface mount termination style for automated PCB assembly. RoHS compliant ensuring compliance with environmental regulations.
Moulded design enhances durability and stability of the component.
This Vishay surface mount inductor is enclosed on a reel packaging for efficient machine insertion processes in manufacturing. Its engineering quality and precision make it an ideal choice for industrial, laboratory, and commercial electronics applications where compact and reliable inductors are required.
Explore the full range of Surface Mount Inductors on EnvMart for advanced electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance of 10 μH with a tolerance of ±20%.
The maximum DC current rating for this inductor is 10 A.
The inductor measures 13.2 mm in length, 6.5 mm in height, and 12.9 mm in depth.
The maximum DC resistance is 17.2 mΩ, which ensures efficient operation.
It operates reliably within a temperature range of -55°C to 125°C.
The maximum self-resonant frequency is 5 MHz, allowing for high frequency applications.
It features a metal composite core, enhancing its magnetic properties.
The inductor is packaged on a reel, facilitating efficient machine insertion processes during manufacturing.
This model has a shielded construction, which reduces noise and electromagnetic interference.
It is suitable for high current POL converters, battery-powered devices, and low profile power supplies.
Yes, it is RoHS compliant, ensuring adherence to environmental safety standards.
The termination style for this inductor is surface mount, suitable for automated PCB assembly.
