Molex SPOX Series Straight Through Hole PCB Header, 8 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 9999-0992
Specifications
| Country of Origin | Malaysia |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | SPOX |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.5mm |
Key Features
- The shrouded design prevents mismating for enhanced safety.
- Single row configuration with 8 male contacts ensures compact layout.
- Brass contact material with tin plating provides excellent conductivity and corrosion resistance.
- Through-hole mount type allows for secure solder connections.
- Operates over a temperature range of -40°C to 105°C suitable for diverse environments.
- Rated for 3A current and 250V voltage applications.
- Friction lock mechanism secures mating connection firmly.
- Tail pin length of 3.5 mm for robust PCB retention.
Product Description
Molex 9999-0992 SPOX Series straight through hole PCB header is a reliable wire-to-board connector designed with 8 male contacts arranged in a single row with 2.5 mm pitch. Featuring a shrouded housing made from durable nylon, this component ensures proper polarization to prevent mismating and incorporates a friction lock for secure connections.
The brass contacts are tin plated for excellent electrical conductivity and corrosion resistance, suitable for demanding applications. This through-hole mounted PCB header can handle currents up to 3A and voltages up to 250V, operating efficiently within temperatures from -40°C to 105°C with a tail pin length of 3.5 mm to assure firm PCB connection stability.
Its low profile and robust construction make it ideal for automotive, consumer electronics, data communications, industrial equipment, medical devices, networking, and telecommunications applications. The friction lock mechanism further improves connection security under vibration or mechanical stress.
The Molex SPOX connectors are engineered for high performance and durability in environments requiring consistent, reliable electrical connections. This 9999-0992 model supports secure, easy assembly and maintenance.
The shrouded design prevents misalignment and potential damage during mating. Polarization features ensure correct mating orientation. Through-hole mounting provides durable mechanical retention. Brass material with tin plating enhances reliability and conductivity.
Wide temperature range covers diverse industrial uses. Compact size suits space-constrained PCB designs. Mechanical friction lock maintains connection integrity in harsh conditions. Multiple industry applications including automotive and telecommunications.
Explore the complete range of Molex connectors and PCB Headers at EnvMart for high-quality electronic components designed to meet precise industry standards and enhance system performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header is rated for a maximum current of 3A.
It has a voltage rating of 250V, making it suitable for a variety of applications.
The contacts of this model have a pitch size of 2.5 mm.
The housing is made from nylon, while the contacts are made of brass with tin plating for improved conductivity and corrosion resistance.
It operates efficiently within a temperature range of -40°C to 105°C.
This model features 8 male contacts arranged in a single row.
It utilizes a through-hole mounting type, allowing for secure solder connections.
The tail pin length is 3.5 mm, ensuring robust PCB retention.
Yes, it features a friction lock mechanism that secures the mating connection firmly.
It is suitable for various applications including automotive, consumer electronics, data communications, industrial equipment, medical devices, networking, and telecommunications.
The orientation of this model is straight, which aids in proper alignment during installation.
The country of origin for this PCB header is Malaysia.
