Nexperia 1.51 V Zener Diode Single 1.3 W 5% Through Hole 2-Pin DO-41 BZV85-C51,113

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.51 V Zener Diode Single 1.3 W 5% Through Hole 2-Pin DO-41 BZV85-C51,113

Name: Nexperia 1.51 V Zener Diode Single 1.3 W 5% Through Hole 2-Pin DO-41 BZV85-C51,113
Brand: Nexperia
SKU: 122702
Price: 0.07 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	2.6mm
Length	4.8mm
Model	BZV85-C51,113
Mount Type	Through Hole
Series	BZV85
Maximum Operating Temperature	200°C
Package Type	DO-41
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	1.3W
Diode Configuration	Single
Test Current It	4mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	51V
Zener Type	Voltage Regulator
Maximum Zener Impedance	125Ω
Typical Voltage Temperature Coefficient	48.65mV/°C
onsemi 1, 51 V Zener Diode, Single 5 W 5 % Through Hole 2-Pin DO-15Brand	onsemi

Key Features

The diode has a nominal Zener voltage of 51 V with a tolerance of 5%.
It features a single diode configuration with 2 pins for through-hole mounting.
Maximum power dissipation is rated at 1.3 W for stable operation.
Test current is 4 mA with maximum Zener impedance of 125 Ω.
The device supports a wide operating temperature range from -65°C to 200°C.
Maximum reverse leakage current is limited to 50 nA for efficiency.
Typical voltage temperature coefficient is 48.65 mV/°C ensuring stable voltage under temperature variations.
The diode comes in the industry-standard DO-41 package with dimensions 4.8 mm length and 2.6 mm height.

Product Description

Nexperia BZV85-C51,113 Zener Diode is a precision voltage regulator diode designed for industrial and electronic component applications. It offers a nominal Zener voltage of 51 V with a tolerance of ±5%, delivering stable voltage regulation with a maximum power dissipation of 1.3 W in a compact DO-41 through hole package.

This diode features a single diode configuration with two pins suitable for through-hole PCB mounting. Its maximum Zener impedance of 125 Ω and low reverse leakage current of 50 nA make it efficient for power supply stabilizing circuits and voltage reference designs.

With an operating temperature range from -65°C to 200°C and a typical voltage temperature coefficient of 48.65 mV/°C, this device is suitable for harsh industrial environments requiring reliable voltage regulation performance over temperature fluctuations.

The product is manufactured in China as part of the BZV85 series by Nexperia, ensuring quality compliance without automotive standard certification. The diode supports stable voltage regulation at a test current of 4 mA.

The DO-41 package dimensions, 4.8 mm length and 2.6 mm height, accommodate standard PCB layouts. Use cases include electronic component manufacturing, industrial power supply circuits, and semiconductor applications. Its through-hole mount type facilitates easy soldering and mechanical stability.

The device is ideal for laboratory, industrial electronics, manufacturing, and power management applications. Explore the electronic components category on EnvMart for similar Zener Diodes and power regulation components by top manufacturers including Nexperia.
