Nexperia 10 V 2 A Schottky Diode 2-Pin Surface Mount SOD-323F PMEG1020EJ,115

Nexperia PMEG1020EJ,115 is a high efficiency Schottky diode designed for electronic and power applications requiring a low forward voltage drop and high thermal performance. Encapsulated in a 2-pin SOD-323F surface mount package, it is optimized for minimal size and excellent electrical characteristics.

This diode provides a maximum continuous forward current of 2 A and a peak reverse repetitive voltage of 10 V, making it suitable for power management, switching regulators, and rectification tasks in compact circuit designs.

The device's peak non-repetitive forward surge current of 9 A ensures reliable operation under transient load conditions. Its maximum forward voltage of 460 mV contributes to efficiency improvements by reducing power loss during conduction.

Operating temperature ranges from -65°C to 150°C, allowing use in demanding industrial, automotive, and commercial electronics environments. Compliance with the automotive standard AEC-Q101 certifies its suitability for automotive electronics applications.

The diode's compact dimensions of 1.8 mm (length) x 1.35 mm (width) x 0.8 mm (height) support high-density PCB assembly, ideal for modern electronics manufacturing. Low leakage current (peak 3 mA) further enhances energy efficiency.

This component is manufactured in China under strict quality control and is widely used in industrial power applications, telecommunications, computing, and consumer electronics where Schottky rectification is required.

This diode supports a maximum continuous forward current of 2 A. It has a peak reverse repetitive voltage rating of 10 V. The device features a maximum forward voltage drop of 460 mV. Designed to operate in temperatures ranging from -65°C to 150°C.

The diode package dimensions are 1.8 mm length, 1.35 mm width, and 0.8 mm height. It has a low leakage current with a peak reverse current of 3 mA. Peak non-repetitive forward surge current rating is 9 A. It meets the automotive standard AEC-Q101 for reliability.

The diode is ideal for high efficiency power applications requiring a Schottky rectifier. Manufactured in China, it ensures quality in surface mount electronic components. Explore our full range of semiconductor components at EnvMart for your industrial, automotive, and electronic design needs.
