| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.01mm |
| Length | 3.04mm |
| Model | MMBZ5V6ALT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | MMBZ A |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Number of Elements per Chip | 2 |
| Clamping Voltage VC | 8V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Common Anode |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 5.32V |
| Maximum Reverse Stand-off Voltage Vwm | 3V |
| Peak Pulse Power Dissipation Pppm | 24W |
| Test Current It | 20mA |
| Maximum Peak Pulse Current Ippm | 3A |
| Maximum Reverse Leakage Current | 5μA |
onsemi MMBZ5V6ALT1G is a 2-element uni-directional transient voltage suppressor (TVS) diode designed for protection against voltage spikes and electrostatic discharge (ESD) in sensitive electronic components. This device dissipates peak pulse power up to 24W in a compact 3-pin SOT-23 surface-mount package, making it suitable for space-constrained PCB layouts.
The diode features a common anode configuration with a minimum breakdown voltage of 5.32V and a maximum reverse stand-off voltage of 3V, providing effective voltage clamping at 8V to protect semiconductor devices and circuits. It operates reliably within a wide temperature range from -55°C to 150°C, supporting demanding industrial, automotive, and communication applications.
Key electrical characteristics include a peak pulse current rating of 3A and a maximum reverse leakage current of 5μA, which contribute to the device's high-performance ESD protection. The diode conforms to the automotive qualification standard AEC-Q101, ensuring robust quality and long-term reliability in automotive and industrial electronic systems.
This TVS diode is ideal for use in computers, printers, communication systems, business machines, and medical equipment where voltage transients and ESD events could otherwise damage critical circuitry. Its compact size and industry-standard pin configuration simplify integration into existing designs while providing effective protection.
This diode has a common anode configuration with uni-directional type suitable for voltage and ESD sensitive applications. The diode supports a minimum breakdown voltage of 5.32V and a maximum reverse stand-off voltage of 3V.
Compact SOT-23 package with 3 pins enables easy surface mounting in circuit designs. Operating temperature range spans from -55°C to 150°C ensuring durability in various industrial environments. The device offers ESD protection with a peak pulse current up to 3A and a clamping voltage of 8V for safeguarding electronics.
Automotive standard compliance AEC-Q101 ensures its reliability in automotive electronic systems.
Explore onsemi TVS Diodes in EnvMart for versatile and dependable transient voltage protection solutions suitable for industrial, automotive, laboratory, and communication electronics applications.
