onsemi 2-Element Uni-Directional TVS Diode Array 500 W, 6-Pin SOT-363 NUP2202W1T2G

onsemi NUP2202W1T2G is a high-performance 2-element uni-directional transient voltage suppressor (TVS) diode array delivering a peak pulse power dissipation of 500 W in a compact SOT-363 surface mount package. This component is designed to provide efficient protection to sensitive semiconductor devices by clamping transient voltage spikes with a clamping voltage of 20 V and peak pulse current capability of 28 A.

The diode array features a complex configuration optimised for uni-directional operation with a minimum breakdown voltage of 6 V and maximum reverse stand-off voltage of 5 V. Its miniature dimensions (0.9 mm height, 2 mm length, and 1.25 mm width) make it ideal for high-density PCB layouts requiring robust electrostatic discharge (ESD) and transient overvoltage protection.

The NUP2202W1T2G supports operation in extreme temperature ranges from -40° C to +125° C, ensuring reliable performance in industrial, automotive, and consumer electronic applications. Its low maximum reverse leakage current of 5 μA reduces power loss and enhances energy efficiency.

This diode array package contains 6 pins and incorporates 2 elements per chip for enhanced surge suppression. It is surface mountable, facilitating automated assembly in manufacturing workflows for electronics, power management, and communication devices.

Complex diode array configuration ensures efficient transient voltage suppression. Uni-directional direction type provides focused protection against voltage spikes. Surface mount SOT-363 package with 6 pins for compact PCB integration.

Operational voltage ratings include 6 V minimum breakdown voltage and 5 V maximum reverse stand-off voltage. Withstands peak pulse currents up to 28 A for high surge tolerance. Minimal height of 0.9 mm, length of 2 mm, and width of 1.25 mm for space-saving applications.

Designed for operating temperature range from -40°C to 125°C for reliable performance. Maximum reverse leakage current is a low 5 μA ensuring minimal power loss. Comes with electrostatic discharge (ESD) protection suitable for sensitive electronics.

Includes 2 elements per chip for enhanced surge arresting capabilities.

This component is ideal for industrial electronics, telecommunications, automotive electronics, power supplies, and consumer electronic protection circuits. onsemi products combine innovation and reliability to safeguard sensitive devices in harsh environments.
