IXYS Thyristor Module 1600 V 800 A Panel Mount SOT-227B 4-Pin MCO50-16IO1

IXYS MCO50-16IO1 Thyristor Module is a high power solid-state semiconductor device featuring a four-layer alternating N and P-type material structure. It functions as a bistable switch, conducting current when triggered at the gate and remaining conductive while forward biased.

This module is encapsulated with an electrically isolated base plate and designed for panel mounting in a compact SOT-227B package. It supports a repetitive peak reverse voltage of 1600 V, rated average on-state current of 54 A, and surge current handling capacity of up to 800 A for transient events.

The maximum gate trigger current is 80 mA, with a gate voltage threshold of 1.4 V. The device maintains robust performance up to a maximum operating temperature of 150°C, making it suitable for demanding industrial applications.

Common applications include battery chargers, welding machines, plating equipment, regulated power supplies, temperature and speed control circuits in industrial and manufacturing environments. Its reliable electrical isolation and compact form factor facilitate safe and efficient integration into power electronics systems.

Rated average on-state current 54 A. Repetitive peak reverse voltage 1600 V. Surge current rating 800 A. Maximum gate trigger current 80 mA. Maximum holding current 100 mA. Encapsulated with isolated base plate. Compact SOT-227B package.

Panel mount type. Maximum operating temperature 150°C. Pin count 4 for easy interfacing.

IXYS is recognized for high quality semiconductor modules with robust electrical and thermal performance. This MCO50-16IO1 model is designed for professionals requiring high power and efficient switching capability in their electronic designs. Explore more power semiconductor modules in the IXYS product range at EnvMart for industrial and commercial power applications.
