IXYS Thyristor SCR 1600 V 19 A Rated Average On-State Current TO-247 Package CS20-16IO1
Specifications
| Country of Origin | India |
|---|---|
| Brand | IXYS |
| Model | CS20-16IO1 |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 125°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 19A |
| Thyristor Type | SCR |
| Repetitive Peak Reverse Voltage VDRM | 1600V |
| Surge Current Rating | 215A |
| Maximum Gate Trigger Current Igt | 65mA |
| Maximum Holding Current Ih | 100mA |
| Maximum Gate Trigger Voltage Vgt | 1V |
| Peak On-State Voltage | 2.1V |
| Repetitive Peak Off-State Current | 2mA |
Key Features
- Features a maximum surge current rating of 215 A suitable for high-current applications.
- Maximum gate trigger current is 65 mA ensuring precise triggering control.
- Designed for operation in temperatures ranging from -40°C to 125°C for robust industrial use.
- Encapsulated with an electrically isolated base plate to enhance thermal management.
- Offers peak on-state voltage of 2.1 V and gate trigger voltage of 1 V.
- Comprises 3 pins with a maximum holding current of 100 mA and repetitive peak off-state current of 2 mA.
- Ideal for phase control, battery chargers, welders, regulated power supplies, and speed control circuits.
- No automotive or other specific industry certifications; compliance with general semiconductor standards.
Product Description
IXYS CS20-16IO1 is a thyristor (SCR) semiconductor device with a rated repetitive peak reverse voltage of 1600 V and rated average on-state current of 19 A. It features a surge current rating up to 215 A and is housed in a TO-247 package suitable for through-hole mounting.
This thyristor is designed with a maximum gate trigger current of 65 mA and maximum holding current of 100 mA, allowing stable and reliable operation in power control applications. It operates at temperatures from -40°C to 125°C, suitable for diverse industrial environments.
The device is encapsulated with an electrically isolated base plate, which improves thermal dissipation and electrical isolation for safety and efficiency. The peak on-state voltage is specified at 2.1 V with a gate trigger voltage of 1 V, ensuring effective switching performance.
Typical applications include phase control in battery chargers, welders, plating equipment, regulated power supplies, and speed or temperature control circuits in industrial machinery. The component complies with semiconductor industry quality norms but does not carry specific automotive standards.
With its 3-pin design and robust electrical specifications, this IXYS thyristor is well suited for precise and high-power applications in laboratory, industrial manufacturing, and power supply domains.
Features a maximum surge current rating of 215 A suitable for high-current applications. Maximum gate trigger current is 65 mA ensuring precise triggering control. Designed for operation in temperatures from -40°C to 125°C for robust industrial use.
Encapsulated with an electrically isolated base plate to enhance thermal management. Offers peak on-state voltage of 2.1 V and gate trigger voltage of 1 V. Comprises 3 pins with a maximum holding current of 100 mA and repetitive peak off-state current of 2 mA.
Ideal for phase control, battery chargers, welders, regulated power supplies, and speed control circuits. No automotive or other specific industry certifications; compliance with general semiconductor standards. Constructed to withstand repetitive peak reverse voltage of 1600 V.
Discover a broad range of semiconductor components and power control devices at EnvMart.
Explore more products in our Thyristors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated average on-state current for this thyristor is 19 A.
This model has a maximum surge current rating of 215 A, making it suitable for high-current applications.
It is designed to operate in temperatures ranging from -40°C to 125°C.
The thyristor is housed in a TO-247 package, which is suitable for through-hole mounting.
The maximum gate trigger current is 65 mA, ensuring precise triggering control.
The peak on-state voltage is specified at 2.1 V.
This thyristor comprises 3 pins.
The maximum holding current is 100 mA.
The maximum gate trigger voltage is 1 V.
This model does not carry specific automotive or other industry certifications but complies with general semiconductor standards.
