Vishay Thyristor SCR 1200 V 10 A 60 mA Gate Trigger Current TO-48 VS-10RIA120

Name: Vishay Thyristor SCR 1200 V 10 A 60 mA Gate Trigger Current TO-48 VS-10RIA120
Brand: Vishay
SKU: 393752
Price: 29.15 USD
Availability: InStock



Category Thyristors Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Model	VS-10RIA120
Mount Type	Screw
Series	VS-10RIA
Maximum Operating Temperature	125°C
Package Type	TO-48
Minimum Operating Temperature	-65°C
Pin Count	2
Rated Average On-State Current Irms	10A
Thyristor Type	SCR
Repetitive Peak Reverse Voltage VDRM	1200V
Surge Current Rating	240A
Maximum Gate Trigger Current Igt	60mA
Maximum Holding Current Ih	130mA
Maximum Gate Trigger Voltage Vgt	2V
Peak On-State Voltage	1.75V
Repetitive Peak Off-State Current	10mA

Key Features

This TO-48 package device operates at repetitive peak reverse voltage of 1200 V.
It features a surge current rating of 240 A for transient conditions.
The maximum gate trigger voltage is 2 V with a maximum holding current of 130 mA.
Suitable for industrial applications such as battery chargers and temperature control systems.
Operates between -65°C minimum and 125°C maximum temperatures.
Controls AC loads efficiently with sharp switching and reliability.
Mounting is via screw type for secure installation.
Pin count of 2 supports streamlined integration into assemblies.

Product Description

Vishay VS-10RIA120 is a high-performance thyristor (SCR) rated at 1200 V repetitive peak reverse voltage and 10 A average on-state current. Packaged in a TO-48 form factor, it integrates advanced silicon-controlled rectifier technology providing robust conduction with a peak surge current handling of 240 A. The device demands a gate trigger current of 60 mA and a gate trigger voltage up to 2 V to initiate conduction, while maintaining a low peak on-state voltage drop of 1.75 V for efficient power management.

Designed for applications in industrial power control, this thyristor is ideal for battery chargers, welding equipment, regulated power supplies, and speed or temperature control circuits. Its construction supports reliable operation over a wide operating temperature range from -65°C to 125°C, and it is mounted with a screw-type fixture ensuring mechanical stability.

The two-pin configuration simplifies integration in electronic control assemblies. This device's capability to handle both repetitive peak off-state currents of 10 mA and surge currents lasting short durations ensures durability in demanding electrical environments.

The VS-10RIA120 series does not carry specific automotive or industry certification approvals, focusing purely on robust, general-purpose performance in discrete semiconductor applications. Although primarily designed for industrial use, it can be employed in laboratory and manufacturing electronic setups requiring precise phase control and reliable switching.

This thyristor delivers precise control of AC power with low gate trigger requirements. It improves efficiency in high power electronic circuits by minimizing voltage drop. Screw-mount design facilitates durable and fast electrical assembly.

Wide operating temperature range supports harsh and variable environmental conditions. TO-48 casing provides compact and stable physical footprint for PCB mounting. High surge current capability ensures tolerance to electrical transients.
