Molex Pico-Lock Series Right Angle Surface PCB Header 12 Contacts 1.5mm Pitch 1 Row Shrouded 504050-1291
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Molex |
| Orientation | Right Angle |
| Current | 2A |
| Mount Type | Surface |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Pico-Lock |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.5mm |
| Standards/Approvals | CSA LR19980, UL E29179 |
| Contact Plating | Gold |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 2mm |
Key Features
- The connector supports a current rating of 2A for efficient power delivery.
- It features a robust housing made of high temperature thermoplastic to endure harsh environments.
- Contacts are constructed from copper alloy with gold plating to ensure excellent conductivity and corrosion resistance.
- Designed for surface mount termination, suitable for compact PCB layouts.
- Operating temperature ranges from -40°C to 105°C, suitable for varied industrial applications.
- Includes a mating pin length of 2 mm for secure connections.
- Complies with CSA LR19980 and UL E29179 standards for safety and performance.
- Compact single-row layout with 1.5 mm row pitch enhances PCB design flexibility.
Product Description
Molex 504050-1291 Pico-Lock Series Right Angle Surface PCB Header features 12 contacts arranged in a single row with 1.5 mm pitch, designed for surface mount PCB applications requiring right-angle orientation. This connector offers a reliable wire-to-board interface with a shrouded design to protect connection integrity.
The high temperature thermoplastic housing provides durability under extreme conditions, with an operating temperature range from -40°C to 105°C, making it suitable for industrial, electronics manufacturing, and aerospace applications. The copper alloy contacts plated in gold ensure high conductivity and resistance to corrosion, enhancing signal reliability and longevity.
This PCB header supports a current capacity of 2A and a voltage rating of 150 Vrms, allowing it to handle moderate power requirements efficiently. The 2 mm mating pin length ensures secure mechanical and electrical connections with compatible connectors.
The shrouded housing and right-angle orientation facilitate ease of use in tight or complex PCB layouts, providing versatile mounting options. It is CSA LR19980 and UL E29179 approved, confirming compliance with stringent safety and quality standards.
Manufactured in Malaysia, this product is ideal for applications in telecommunications, consumer electronics, industrial machinery, and other commercial PCB assemblies. The connector provides 12 gold-plated contacts for optimal electrical performance.
Right-angle orientation enables flexible board layout designs. High temperature thermoplastic housing withstands extreme environments. Electrical ratings include 2A current and 150 Vrms voltage. Surface mount termination offers compact, reliable installation.
Operating temperature from -40°C to 105°C covers diverse conditions. Mating pin length of 2 mm assures reliable connectivity. Shrouded design enhances connection safety and durability. Certified to CSA and UL safety standards.
This Molex Pico-Lock PCB header is an essential component for reliable, high-performance electronic assemblies in industrial, commercial, and manufacturing sectors. Explore more PCB Headers and connectors at EnvMart for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 2A, making it suitable for moderate power requirements.
The operating temperature range for this model is from -40°C to 105°C, allowing it to function in diverse environmental conditions.
The contacts are constructed from copper alloy and are plated with gold to ensure excellent conductivity and corrosion resistance.
This connector features 12 contacts arranged in a single row.
This model utilizes surface mount termination, which is suitable for compact PCB layouts.
The pitch of the contacts on this PCB header is 1.5mm, enhancing PCB design flexibility.
The mating pin length for this connector is 2mm, ensuring secure connections with compatible connectors.
This model complies with CSA LR19980 and UL E29179 standards, confirming its safety and performance.
The housing is made of high temperature thermoplastic, providing durability in harsh environments.
This connector has a right-angle orientation, facilitating ease of use in tight or complex PCB layouts.
This PCB header is suitable for applications in telecommunications, consumer electronics, industrial machinery, and other commercial PCB assemblies.
This product is manufactured in Malaysia, ensuring compliance with international standards.
